HTTPRequest class represents a HTTP request. More...

#include <httprequest.hpp>

Inheritance diagram for dodo::network::protocol::http::HTTPRequest:

Collaboration diagram for dodo::network::protocol::http::HTTPRequest:

Data Structures
class	HTTPRequestLine
	HTTPRequestLine class. More...

Public Types
enum	Method { meGET, meHEAD, mePOST, mePUT, mePATCH, meDELETE, meCONNECT, meOPTIONS, meTRACE, meINVALID }
	The HTTP request method. More...

Public Types inherited from dodo::network::protocol::http::HTTPFragment
enum	ParseError : unsigned int { peOk = 0, peIncomplete, peSystemError, peExpectCRLF, peUnFinishedToken, peExpectingHeaderColon, peInvalidHeaderFieldValue, peInvalidHeaderListEnd, peInvalidMethod, peInvalidHTTPVersion, peInvalidRequestLine, peInvalidContentLength, peUnexpectedBody, peInvalidTransferEncoding, peInvalidChunkHex, peInvalidLastChunk, peExpectingUnsignedInt }
	Parse results returned by the parse functions. More...

Public Member Functions
virtual std::string	asString () const
	Return the HTTPRequest as a string. More...

HTTPRequestLine &	getRequestLine ()
	Get the HTTPRequestLine. More...

virtual ParseResult	parse (VirtualReadBuffer &data)
	Read the HTTPRequest from the socket. More...

virtual ParseResult	parseBody (VirtualReadBuffer &data)
	Parse a body and resturn it as a single string. More...

virtual common::SystemError	send (BaseSocket *socket)
	Send this HTTPMessage to the socket. More...

void	setRequestLine (const HTTPRequestLine &req)
	Set the HTTPRequestLine. More...

common::SystemError	write (BaseSocket *socket) const
	Write the HTTPRequest to the socket. More...

Public Member Functions inherited from dodo::network::protocol::http::HTTPMessage
	HTTPMessage ()
	Default constructor. More...

void	addHeader (const std::string &key, const std::string &value)
	Add a header to the HTTPMessage. More...

void	clearHeaders ()
	Clear all headers. More...

const common::Bytes &	getBody () const
	Return the HTTTMessage body. More...

const std::map< std::string, std::string > &	getHeaders () const
	Return a reference to the headers map. More...

bool	getHeaderValue (const std::string &key, std::string &value) const
	Get a header value as a string into value. More...

bool	getHeaderValue (const std::string &key, unsigned long &value) const
	Get a header value as an unsigned long into value. More...

bool	hasHeader (const std::string &header) const
	Return true when this header key exists in this HTTPMessage's headers. More...

void	replaceHeader (const std::string &key, const std::string &value)
	Replace the value of a header. More...

void	setBody (const std::string &body)
	Set the body. More...

Static Public Member Functions
static bool	methodAllowsBody (Method method)
	Return true if the Method allows a body in the message. More...

static std::string	methodAsString (Method method)
	Translate a Method enum to a human readable string. More...

static Method	methodFromString (const std::string &s)
	Translate an uppercase string ('GET', "POST', ..) into a Method enum. More...

Static Public Member Functions inherited from dodo::network::protocol::http::HTTPFragment
static std::string	getParseResultAsString (ParseError error)
	Return the string description of a ParseError. More...

Protected Attributes
HTTPRequestLine	request_line_
	The HTTPRequestLine of the HTTPRequest. More...

Protected Attributes inherited from dodo::network::protocol::http::HTTPMessage
common::Bytes	body_
	The message body (if any). More...

std::map< std::string, std::string >	headers_
	The message headers. More...

Additional Inherited Members
Static Public Attributes inherited from dodo::network::protocol::http::HTTPMessage
static const char	charCR = char(13)
	CR character. More...

static const char	charHT = char(9)
	Horizontal tab character. More...

static const char	charLF = char(10)
	LF character. More...

static const char	charSP = char(32)
	Space character. More...

Protected Member Functions inherited from dodo::network::protocol::http::HTTPMessage
ParseResult	eatCRLF (VirtualReadBuffer &data)
	Consume a CR LF sequence only when it is there. More...

ParseResult	parseChunkedBody (VirtualReadBuffer &data)
	Parse a chunked body (transfer-encoding: chunked) and resturn it as a single string. More...

ParseResult	parseChunkHex (VirtualReadBuffer &data, unsigned long &value)
	Parse a hexadecimal chunk size (a hex value followed by CR LF). More...

ParseResult	parseCRLF (VirtualReadBuffer &data)
	Consume a CR LF sequence. More...

ParseResult	parseFieldValue (VirtualReadBuffer &data, std::string &value)
	Parse a header field value. More...

ParseResult	parseHeaders (VirtualReadBuffer &data)
	Parse a header section and update headers_. More...

ParseResult	parseToken (VirtualReadBuffer &buffer, std::string &token)
	Parse a token (such as a header field name). More...

Static Protected Member Functions inherited from dodo::network::protocol::http::HTTPMessage
static common::SystemError	eatSpace (VirtualReadBuffer &data)
	Call buffer.next() as long as buffer.get() is whitespace ( charSP or charHT). More...

static bool	isCTL (char c)
	Check is the char is a CTL character. More...

static bool	isSeparator (char c)
	Return true if the char is a separator. More...

static bool	isSP (char c)
	Return true if the char is whitespace character (charSP or charHT) More...

static ParseResult	parseUInt (VirtualReadBuffer &data, unsigned int &value)
	Parse an unsigned integer. More...

Detailed Description

HTTPRequest class represents a HTTP request.

A HTTPRequest contains

A HTTPRequestLine
An optional body of type common::Bytes.

#include <iostream>

#include <dodo.hpp>

using namespace dodo::network;
using namespace dodo::network::protocol::http;
using namespace dodo::common;

const std::string host = "httpbin.org";

struct RTStats {
  double dns_time = 0.0;
  double handshake_time = 0.0;
  double send_time = 0.0;
  double read_time = 0.0;
  size_t body_bytes = 0;
  size_t underflows = 0;
};

// argv[1] = host
// argv[2] = method
// argv[3] = uri
int main( int argc, char* argv[] ) {
  if ( argc < 4 ) return 1;
  int error = 0;
  RTStats rtstats;
  std::string host = argv[1];
  std::string method = argv[2];
  std::string uri = argv[3];
  try {
    dodo::initLibrary();

    StopWatch sw;

    SocketParams sockparams( SocketParams::AddressFamily::afUNSPEC, SocketParams::stSTREAM, SocketParams::pnTCP );
    X509Common::SAN san = {  X509Common::SANType::stDNS, host };
    Address address;
    std::string canonicalname = "";
    sw.start();
    SystemError syserr = Address::getHostAddrInfo( host, sockparams, address, canonicalname );
    rtstats.dns_time = sw.getElapsedSeconds();
    if ( syserr.ok() ) {
      std::cout << host << " = " << address.asString() << std::endl;
      TLSContext tlscontext( TLSContext::PeerVerification::pvVerifyFQDN, TLSContext::TLSVersion::tls1_1, true );
      tlscontext.setOptions( SSL_OP_ALL );
      TLSSocket sock( true, sockparams, tlscontext, san );
      sock.setReceiveBufSize( 8192*100 );
      address.setPort( 443 );
      syserr = sock.connect( address );
      rtstats.handshake_time = sw.getElapsedSeconds();
      if( syserr.ok() ) {
        HTTPRequest req;
        req.getRequestLine().setHTTPVersion( HTTPVersion(1,1) );
        req.getRequestLine().setMethod( HTTPRequest::methodFromString( method ) );
        req.getRequestLine().setRequestURI( uri );
        req.addHeader( "host", host );
        std::cout << "----------------------------------- BEGIN REQ -----------------------------------" << std::endl;
        std::cout << req.asString() << std::endl;
        std::cout << "----------------------------------- END   REQ -----------------------------------" << std::endl;
        //syserr = sock.send( req.asString().c_str(), req.asString().length() );
        syserr = req.send( &sock );
        rtstats.send_time = sw.getElapsedSeconds();
        if ( syserr.ok() ) {
          SocketReadBuffer rbuf( &sock );
          syserr = rbuf.underflow();
          if ( syserr.ok() ) {
            HTTPResponse resp;
            HTTPFragment::ParseResult parse_result = resp.parse( rbuf );
            rtstats.read_time = sw.getElapsedSeconds();
            if ( parse_result.ok() ) {
              rtstats.underflows = rbuf.getUnderflowCount();
              std::cout << "----------------------------------- BEGIN RSP -----------------------------------" << std::endl;
              std::cout << resp.asString() << std::endl;
              rtstats.body_bytes = resp.asString().length();
              std::cout << "----------------------------------- END   RSP -----------------------------------" << std::endl;
            } else {
              std::cerr << "invalid HTTP response: " << parse_result.asString() << std::endl;
              error = 1;
            }
          } else {
            std::cerr << "socket read error: " << syserr.asString() << std::endl;
            error = 1;
          }
          rtstats.read_time = sw.getElapsedSeconds();

        } else {
          std::cerr << "send failed: " << syserr.asString() << std::endl;
          error = 1;
        }

      } else {
        std::cerr << "connect failed: " << syserr.asString() << std::endl;
        error = 1;
      }
    } else {
      std::cerr << "resolving of " << host << " failed : " << syserr.asString() << std::endl;
    }
  }
  catch ( const std::exception &e ) {
    std::cerr << e.what() << std::endl;
    error =  1;
  }
  std::cout << "DNS       " << std::fixed << std::setprecision(3) << rtstats.dns_time*1000 << "ms" << std::endl;
  std::cout << "HANDSHAKE " << std::fixed << std::setprecision(3) << rtstats.handshake_time*1000 << "ms" << std::endl;
  std::cout << "SEND      " << std::fixed << std::setprecision(3) << rtstats.send_time*1000 << "ms" << std::endl;
  std::cout << "RECEIVE   " << std::fixed << std::setprecision(3) << rtstats.read_time*1000 << "ms" << std::endl;
  std::cout << "RSP body size " << std::fixed << std::setprecision(0) << rtstats.body_bytes << "B" << std::endl;
  std::cout << "receive underflows " << std::fixed << std::setprecision(0) << rtstats.underflows << std::endl;
  if ( rtstats.underflows ) std::cout << "receive bytes / roundtrip " << std::fixed << std::setprecision(0) << rtstats.body_bytes/rtstats.underflows << std::endl;
  dodo::closeLibrary();
  return error;
}

Definition at line 42 of file httprequest.hpp.

Member Enumeration Documentation

◆ Method

enum dodo::network::protocol::http::HTTPRequest::Method

The HTTP request method.

Enumerator
meINVALID	The parser was presented an invalid method.

Definition at line 48 of file httprequest.hpp.

Member Function Documentation

◆ asString()

std::string dodo::network::protocol::http::HTTPRequest::asString ( ) const

virtual

Return the HTTPRequest as a string.

Returns: the HTTPRequest as a string.

Implements dodo::network::protocol::http::HTTPFragment.

Definition at line 86 of file httprequest.cpp.

References dodo::network::protocol::http::HTTPRequest::HTTPRequestLine::asString(), dodo::common::Bytes::asString(), dodo::network::protocol::http::HTTPMessage::body_, dodo::network::protocol::http::HTTPMessage::charCR, dodo::network::protocol::http::HTTPMessage::charLF, dodo::network::protocol::http::HTTPRequest::HTTPRequestLine::getMethod(), dodo::common::Bytes::getSize(), dodo::network::protocol::http::HTTPMessage::headers_, methodAllowsBody(), and request_line_.

Referenced by write().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getRequestLine()

HTTPRequestLine& dodo::network::protocol::http::HTTPRequest::getRequestLine ( )

inline

Get the HTTPRequestLine.

Returns: The HTTPRequestLine.

Definition at line 170 of file httprequest.hpp.

References request_line_.

◆ methodAllowsBody()

bool dodo::network::protocol::http::HTTPRequest::methodAllowsBody ( Method method )

static

Return true if the Method allows a body in the message.

Parameters

method the Method to check.

Returns: if the Method allows a body.

Definition at line 60 of file httprequest.cpp.

Referenced by asString(), and send().

Here is the caller graph for this function:

◆ methodAsString()

std::string dodo::network::protocol::http::HTTPRequest::methodAsString ( Method method )

static

Translate a Method enum to a human readable string.

Parameters

method The method to translate.

Returns: the string.

Definition at line 32 of file httprequest.cpp.

Referenced by dodo::network::protocol::http::HTTPRequest::HTTPRequestLine::asString().

Here is the caller graph for this function:

◆ methodFromString()

HTTPRequest::Method dodo::network::protocol::http::HTTPRequest::methodFromString ( const std::string & s )

static

Translate an uppercase string ('GET', "POST', ..) into a Method enum.

Parameters

s	The uppercase string to translate.

Returns: the Method (and meINVALID if the string is not a Method).

Definition at line 47 of file httprequest.cpp.

References meINVALID.

Referenced by dodo::network::protocol::http::HTTPRequest::HTTPRequestLine::parse().

Here is the caller graph for this function:

◆ parse()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPRequest::parse ( VirtualReadBuffer & data )

virtual

Read the HTTPRequest from the socket.

Parameters

data	The VirtualReadBuffer to read from.

Returns: The ParseResult.

Implements dodo::network::protocol::http::HTTPFragment.

Definition at line 114 of file httprequest.cpp.

Here is the call graph for this function:

◆ parseBody()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPRequest::parseBody ( VirtualReadBuffer & data )

virtual

Parse a body and resturn it as a single string.

Note that the content-length header must be present and specify the correct body length.

Parameters

data	The VirtualReadBuffer to read from.

Returns: The ParseError.

Implements dodo::network::protocol::http::HTTPMessage.

Definition at line 139 of file httprequest.cpp.

References dodo::common::Bytes::append(), dodo::network::protocol::http::HTTPMessage::body_, dodo::common::SystemError::ecOK, dodo::network::VirtualReadBuffer::get(), dodo::network::protocol::http::HTTPMessage::getHeaderValue(), dodo::network::VirtualReadBuffer::next(), dodo::network::protocol::http::HTTPFragment::ParseResult::ok(), dodo::network::protocol::http::HTTPMessage::parseChunkedBody(), dodo::network::protocol::http::HTTPFragment::peInvalidTransferEncoding, dodo::network::protocol::http::HTTPFragment::peUnexpectedBody, and dodo::network::protocol::http::HTTPFragment::ParseResult::setSystemError().

Referenced by parse().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ send()

common::SystemError dodo::network::protocol::http::HTTPRequest::send ( BaseSocket * socket )

virtual

Send this HTTPMessage to the socket.

Parameters

socket The socket to write to.

Returns: The commonSystemError that might accour.

Implements dodo::network::protocol::http::HTTPMessage.

Definition at line 99 of file httprequest.cpp.

References dodo::network::protocol::http::HTTPRequest::HTTPRequestLine::asString(), dodo::network::protocol::http::HTTPMessage::body_, dodo::network::protocol::http::HTTPMessage::charCR, dodo::network::protocol::http::HTTPMessage::charLF, dodo::common::Bytes::getArray(), dodo::network::protocol::http::HTTPRequest::HTTPRequestLine::getMethod(), dodo::common::Bytes::getSize(), dodo::network::protocol::http::HTTPMessage::headers_, methodAllowsBody(), dodo::common::SystemError::ok(), request_line_, and dodo::network::BaseSocket::send().

Here is the call graph for this function:

◆ setRequestLine()

void dodo::network::protocol::http::HTTPRequest::setRequestLine ( const HTTPRequestLine & req )

Set the HTTPRequestLine.

Parameters

req	The HTTPRequestLine to set.

◆ write()

common::SystemError dodo::network::protocol::http::HTTPRequest::write ( BaseSocket * socket ) const

Write the HTTPRequest to the socket.

Parameters

socket The BaseSocket to write to.

Returns: The SystemError.

Definition at line 249 of file httprequest.cpp.

References asString(), and dodo::network::BaseSocket::send().

Here is the call graph for this function:

Field Documentation

◆ request_line_

HTTPRequestLine dodo::network::protocol::http::HTTPRequest::request_line_

protected

The HTTPRequestLine of the HTTPRequest.

Definition at line 208 of file httprequest.hpp.

Referenced by asString(), getRequestLine(), parse(), and send().

The documentation for this class was generated from the following files:

src/include/network/protocol/http/httprequest.hpp
src/lib/network/protocol/http/httprequest.cpp

Data Structures

Public Types

Public Member Functions

Static Public Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Member Enumeration Documentation

◆ Method

Member Function Documentation

◆ asString()

◆ getRequestLine()

◆ methodAllowsBody()

◆ methodAsString()

◆ methodFromString()

◆ parse()

◆ parseBody()

◆ send()

◆ setRequestLine()

◆ write()

Field Documentation

◆ request_line_
