Generic network Address, supporting ipv4 and ipv6 transparently. More...

#include <address.hpp>

Inheritance diagram for dodo::network::Address:

Collaboration diagram for dodo::network::Address:

Public Member Functions
	Address ()
	Construct an invalid (unspecified) address. More...

	Address (const Address &address)
	Copy from Address. More...

	Address (const sockaddr *address, socklen_t len)
	Construct from sockaddr *. More...

	Address (const sockaddr_storage &address)
	Construct from sockaddr_storage. More...

	Address (const std::string &ip)
	Construct from ip, do not set port (only a listening socket needs a port preset). More...

	Address (const std::string &ip, uint16_t port)
	Construct from "ip", port. More...

std::string	asString (bool withport=false) const
	Return a string representation of this Address. More...

const sockaddr_storage *	getAddress () const
	Get to the underlying sockaddr_storage. More...

SocketParams::AddressFamily	getAddressFamily () const
	Get this Address family. More...

common::SystemError	getNameInfo (std::string &hostname) const
	Do a reverse DNS lookup on this Address and return in hostname. More...

common::SystemError	getNameInfo (std::string &hostname, std::string &service) const
	Do a reverse DNS lookup on this Address and its port, and return in hostname and service. More...

common::SystemError	getNameInfo (std::string &hostname, uint16_t &port) const
	Do a reverse DNS lookup on this Address and its port, and return in hostname and port. More...

uint16_t	getPort () const
	Return the port number. More...

bool	isValid () const
	True if this Address is valid. More...

Address &	operator= (const Address &address)
	Assign (copy) from Address. More...

Address &	operator= (const sockaddr_storage &address)
	Assign from sockaddr_storage. More...

Address &	operator= (const std::string &address)
	Assign from "ip" string. More...

bool	operator== (const Address &address) const
	Test for equality. More...

void	setPort (uint16_t port)
	Set the port number. More...

Public Member Functions inherited from dodo::common::DebugObject
	DebugObject ()
	Default constructor does nothing. More...

virtual	~DebugObject ()
	Destructor does nothing. More...

std::string	debugString () const
	Return the object dump to string. More...

Static Public Member Functions
static common::SystemError	getHostAddrInfo (const std::string &hostname, AddrInfo &info)
	Get Address information on a host in a AddrInfo struct. More...

static common::SystemError	getHostAddrInfo (const std::string &hostname, SocketParams &params, Address &address, std::string &canonicalname)
	Return the first hit on SocketParams in address and canonicalname. More...

Private Member Functions
struct sockaddr_in *	asIPv4Address () const
	Explicit cast of addr_ as sockaddr_in*. More...

struct sockaddr_in6 *	asIPv6Address () const
	Explicit cast of addr_ as sockaddr_in6*. More...

void	init ()
	Initialize the internals. More...

Private Attributes
struct sockaddr_storage	addr_
	The address storage (for either ipv4 or ipv6). More...

Friends
class	BaseSocket
	BaseSocket may access this class directly. More...

class	Socket
	Socket may access this class directly. More...

Additional Inherited Members
Protected Member Functions inherited from dodo::common::DebugObject
virtual std::string	debugDetail () const
	Descendant classes can override to dump details specific to the class. More...

std::string	debugHeader () const
	Generates a debug header (address of this object and a demangled class name. More...

Detailed Description

Generic network Address, supporting ipv4 and ipv6 transparently.

Typical client use is to first resolve a host name. We specify SocketParams::afUNSPEC for the address family, allowing for both ipv4 and ipv6 and specify the TCP protocol (stSTRAM + pnTCP ).

using namespace dodo::common;
using namespace dodo::network;

Address address;
SocketParams sock_params = SocketParams( SocketParams::afUNSPEC,
                                         SocketParams::stSTREAM,
                                         SocketParams::pnTCP );
std::string canonicalname;
SystemError error = Address::getHostAddrInfo( "httpbin.org", sock_params, address, canonicalname );

The canonical name is set and may differ from the host name passed to getHostAddrInfo.

After the getHostAddrInfo (if error == SystemError::ecOK ) the sock_params will have its address family set to either network::SocketParams::afINET or network::SocketParams::afINET6, depending on what the server (httpbin.org) supports. But we can continue to connect without any reference to the actual address family being used:

if ( error == SystemError::ecOK ) {
  address.setPort( 443 );
  Socket socket( true, sock_params );
  error = socket.connect( address );
  if ( error == SystemError::ecOK ) {
    // connected
  }
}

There are two prototypes for getHostAddrInfo, one returns the preferred Address (as above), the other a list of addresses (an AddrInfo structure), the preferred address the first in the list. Subsequent calls do not necessarily (under DNS round robin for example) return the same address as preferred address.

As the getHostAddrInfo calls are quite expensive, prefer reuse of obtained Address objects where possible.

Special addresses	ipv4	ipv6
INADDR_ANY	0.0.0.0	::0
localhost	127.0.0.1	::1

Definition at line 90 of file address.hpp.

Constructor & Destructor Documentation

◆ Address() [1/6]

dodo::network::Address::Address ( )

inline

Construct an invalid (unspecified) address.

Definition at line 96 of file address.hpp.

References addr_.

Referenced by getHostAddrInfo().

Here is the caller graph for this function:

◆ Address() [2/6]

dodo::network::Address::Address	(	const std::string &	ip,
		uint16_t	port
	)

Construct from "ip", port.

Parameters

ip	The string representation of the ip, either ipv4 or ipv6.
port	The port number (only specified for listen addresses).

Definition at line 40 of file address.cpp.

References init(), and setPort().

Here is the call graph for this function:

◆ Address() [3/6]

dodo::network::Address::Address ( const std::string & ip )

Construct from ip, do not set port (only a listening socket needs a port preset).

Parameters

ip	The string representation of the ip, either ipv4 or ipv6.

Definition at line 35 of file address.cpp.

References init().

Here is the call graph for this function:

◆ Address() [4/6]

dodo::network::Address::Address ( const sockaddr_storage & address )

Construct from sockaddr_storage.

Parameters

address A sockaddr_storage structure.

Definition at line 46 of file address.cpp.

References addr_.

◆ Address() [5/6]

dodo::network::Address::Address	(	const sockaddr *	address,
		socklen_t	len
	)

Construct from sockaddr *.

Parameters

address	A const sockaddr*
len	And its length.

Definition at line 51 of file address.cpp.

References addr_.

◆ Address() [6/6]

dodo::network::Address::Address ( const Address & address )

Copy from Address.

Parameters

address Source address to copy from.

Definition at line 56 of file address.cpp.

References addr_.

Member Function Documentation

◆ asIPv4Address()

struct sockaddr_in* dodo::network::Address::asIPv4Address ( ) const

inlineprivate

Explicit cast of addr_ as sockaddr_in*.

Returns: The pointer.

Definition at line 278 of file address.hpp.

References addr_.

Referenced by asString(), getPort(), operator=(), operator==(), and setPort().

Here is the caller graph for this function:

◆ asIPv6Address()

struct sockaddr_in6* dodo::network::Address::asIPv6Address ( ) const

inlineprivate

Explicit cast of addr_ as sockaddr_in6*.

Returns: The pointer.

Definition at line 284 of file address.hpp.

References addr_.

Referenced by asString(), getPort(), operator=(), operator==(), and setPort().

Here is the caller graph for this function:

◆ asString()

std::string dodo::network::Address::asString ( bool withport = false ) const

Return a string representation of this Address.

Parameters

withport If true, append ':' + port number.

Returns: string representation of this Address.

Definition at line 107 of file address.cpp.

References addr_, asIPv4Address(), asIPv6Address(), getPort(), and throw_SystemExceptionObject.

Referenced by dodo::network::AddrInfoItem::asString(), dodo::network::BaseSocket::bind(), dodo::network::TCPListener::construct(), dodo::network::BaseSocket::listen(), dodo::network::TCPServer::run(), and dodo::network::TCPListener::run().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getAddress()

const sockaddr_storage* dodo::network::Address::getAddress ( ) const

inline

Get to the underlying sockaddr_storage.

Returns: A pointer to the underlying socket storage.

Definition at line 165 of file address.hpp.

References addr_.

Referenced by dodo::network::BaseSocket::connect().

Here is the caller graph for this function:

◆ getAddressFamily()

SocketParams::AddressFamily dodo::network::Address::getAddressFamily ( ) const

inline

Get this Address family.

Returns: The address family of this Address.

Definition at line 159 of file address.hpp.

References addr_.

Referenced by dodo::network::TCPListener::construct(), and getHostAddrInfo().

Here is the caller graph for this function:

◆ getHostAddrInfo() [1/2]

common::SystemError dodo::network::Address::getHostAddrInfo	(	const std::string &	hostname,
		AddrInfo &	info
	)

static

Get Address information on a host in a AddrInfo struct.

Could return the following SystemError

SystemError::ecOK
SystemError::ecEAI_ADDRFAMILY (The hosts exists but has not address in the requested address family)
SystemError::ecEAI_NODATA (The hosts exists in DNS but has no addresses)
SystemError::ecEAI_NONAME (The hosts does not exist in DNS)

Parameters

hostname	The host name to lookup.
info	The AddrInfo structure to fill.

Returns: SystemError::ecOK if the lookup resulted in at least one address.

Definition at line 144 of file address.cpp.

References Address(), dodo::network::AddrInfoItem::address, dodo::network::AddrInfo::canonicalname, dodo::common::SystemError::ecEAI_ADDRFAMILY, dodo::common::SystemError::ecEAI_NODATA, dodo::common::SystemError::ecEAI_NONAME, dodo::common::SystemError::ecOK, dodo::network::AddrInfo::items, dodo::network::AddrInfoItem::params, dodo::network::SocketParams::setAddressFamily(), dodo::network::SocketParams::setProtocol(), dodo::network::SocketParams::setSocketType(), and throw_SystemException.

Referenced by getHostAddrInfo().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getHostAddrInfo() [2/2]

common::SystemError dodo::network::Address::getHostAddrInfo	(	const std::string &	hostname,
		SocketParams &	params,
		Address &	address,
		std::string &	canonicalname
	)

static

Return the first hit on SocketParams in address and canonicalname.

Could return the following SystemError

SystemError::ecOK
SystemError::ecEAI_ADDRFAMILY (The hosts exists but has not address in the requested address family)
SystemError::ecEAI_NODATA (The hosts exists in DNS but has no addresses)
SystemError::ecEAI_NONAME (The hosts does not exist in DNS)

Parameters

hostname	The host name to lookup.
params	The SocketParams the entry must match to.
address	The result address (set to invalid when this call returns an error).
canonicalname	The canonicalname of hostname (set to "" when this call returns an error).

Returns: SystemError::ecOK if the lookup resulted in an address.

Definition at line 177 of file address.cpp.

References Address(), dodo::network::AddrInfo::canonicalname, dodo::common::SystemError::ecEAI_NODATA, dodo::common::SystemError::ecOK, dodo::network::SocketParams::getAddressFamily(), getAddressFamily(), getHostAddrInfo(), dodo::network::SocketParams::getProtocol(), dodo::network::SocketParams::getSocketType(), dodo::network::AddrInfo::items, and dodo::network::SocketParams::setAddressFamily().

Here is the call graph for this function:

◆ getNameInfo() [1/3]

common::SystemError dodo::network::Address::getNameInfo ( std::string & hostname ) const

Do a reverse DNS lookup on this Address and return in hostname.

Could return the following SystemError

SystemError::ecOK
SystemError::ecEAI_AGAIN
SystemError::ecEAI_BADFLAGS
SystemError::ecEAI_FAIL
SystemError::ecEAI_FAMILY
SystemError::ecEAI_MEMORY
SystemError::ecEAI_NONAME
SystemError::ecEAI_OVERFLOW
SystemError::ecEAI_SYSTEM is silently replaced by errno
Parameters

hostname The string to receive the hostname.

Returns
The error or SystemError::ecOK on success.

Definition at line 200 of file address.cpp.

References addr_, and dodo::common::SystemError::ecEAI_SYSTEM.

◆ getNameInfo() [2/3]

common::SystemError dodo::network::Address::getNameInfo	(	std::string &	hostname,
		std::string &	service
	)		const

Do a reverse DNS lookup on this Address and its port, and return in hostname and service.

Parameters

hostname	The string variable to receive the hostname.
service	The string variable to receive the service name.

Returns: The error or SystemError::ecOK on success.

See also: getNameInfo() for a full list of possible errors returned.

Definition at line 214 of file address.cpp.

References addr_, and dodo::common::SystemError::ecEAI_SYSTEM.

◆ getNameInfo() [3/3]

common::SystemError dodo::network::Address::getNameInfo	(	std::string &	hostname,
		uint16_t &	port
	)		const

Do a reverse DNS lookup on this Address and its port, and return in hostname and port.

Parameters

hostname	The string variable to receive the hostname.
port	The uint16_t variable to receive the port number.

Returns: The error or SystemError::ecOK on success.

See also: getNameInfo() for a full list of possible errors returned.

Definition at line 229 of file address.cpp.

References addr_, dodo::common::SystemError::ecEAI_SYSTEM, and throw_SystemException.

◆ getPort()

uint16_t dodo::network::Address::getPort ( ) const

Return the port number.

Returns: The port number.

Definition at line 127 of file address.cpp.

References addr_, asIPv4Address(), and asIPv6Address().

Referenced by asString().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ init()

void dodo::network::Address::init ( )

private

Initialize the internals.

Definition at line 61 of file address.cpp.

References addr_.

Referenced by Address().

Here is the caller graph for this function:

◆ isValid()

bool dodo::network::Address::isValid ( ) const

inline

True if this Address is valid.

Returns: true when this Address is valid.

Definition at line 134 of file address.hpp.

References addr_.

Referenced by dodo::network::TCPListener::construct(), dodo::network::TCPListener::TCPListener(), and dodo::network::X509Certificate::verifyIP().

Here is the caller graph for this function:

◆ operator=() [1/3]

Address & dodo::network::Address::operator= ( const Address & address )

Assign (copy) from Address.

Parameters

address The Address to assign.

Returns: This Address.

Definition at line 82 of file address.cpp.

References addr_.

◆ operator=() [2/3]

Address & dodo::network::Address::operator= ( const sockaddr_storage & address )

Assign from sockaddr_storage.

Parameters

address The address to assign in sockaddr_storage form.

Returns: This Address.

Definition at line 87 of file address.cpp.

References addr_.

◆ operator=() [3/3]

Address & dodo::network::Address::operator= ( const std::string & address )

Assign from "ip" string.

Parameters

address The address to assign in string form.

Returns: This Address.

Definition at line 66 of file address.cpp.

References addr_, asIPv4Address(), and asIPv6Address().

Here is the call graph for this function:

◆ operator==()

bool dodo::network::Address::operator== ( const Address & address ) const

Test for equality.

The comparison is a byte compare on the internal sockaddr_in / sockaddr_in6 structures, which guarantees that Address objects assigned "::1" and "0:0:0:0:0:0:0:1" are considered equal.

Parameters

address The address to compare to.

Returns: True if the addresses are equal.

Definition at line 92 of file address.cpp.

References addr_, asIPv4Address(), and asIPv6Address().

Here is the call graph for this function:

◆ setPort()

void dodo::network::Address::setPort ( uint16_t port )

Set the port number.

Parameters

port	The new port number.

Definition at line 136 of file address.cpp.

References addr_, asIPv4Address(), and asIPv6Address().

Referenced by Address().

Here is the call graph for this function:

Here is the caller graph for this function:

Friends And Related Function Documentation

◆ BaseSocket

friend class BaseSocket

friend

BaseSocket may access this class directly.

Definition at line 298 of file address.hpp.

◆ Socket

friend class Socket

friend

Socket may access this class directly.

Definition at line 294 of file address.hpp.

Field Documentation

◆ addr_

struct sockaddr_storage dodo::network::Address::addr_

private

The address storage (for either ipv4 or ipv6).

Definition at line 289 of file address.hpp.

Referenced by Address(), asIPv4Address(), asIPv6Address(), asString(), dodo::network::BaseSocket::bind(), getAddress(), getAddressFamily(), getNameInfo(), getPort(), init(), isValid(), operator=(), operator==(), dodo::network::Socket::sendTo(), and setPort().

The documentation for this class was generated from the following files:

src/include/network/address.hpp
src/lib/network/address.cpp

Public Member Functions

Static Public Member Functions

Private Member Functions

Private Attributes

Friends

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ Address() [1/6]

◆ Address() [2/6]

◆ Address() [3/6]

◆ Address() [4/6]

◆ Address() [5/6]

◆ Address() [6/6]

Member Function Documentation

◆ asIPv4Address()

◆ asIPv6Address()

◆ asString()

◆ getAddress()

◆ getAddressFamily()

◆ getHostAddrInfo() [1/2]

◆ getHostAddrInfo() [2/2]

◆ getNameInfo() [1/3]

◆ getNameInfo() [2/3]

◆ getNameInfo() [3/3]

◆ getPort()

◆ init()

◆ isValid()

◆ operator=() [1/3]

◆ operator=() [2/3]

◆ operator=() [3/3]

◆ operator==()

◆ setPort()

Friends And Related Function Documentation

◆ BaseSocket

◆ Socket

Field Documentation

◆ addr_
