Socket parameters - the family (domain), socket type and protocol triplet. More...

#include <socketparams.hpp>

Collaboration diagram for dodo::network::SocketParams:

[legend]

Public Types
enum	AddressFamily { afLOCAL = AF_LOCAL, afINET = AF_INET, afINET6 = AF_INET6, afIPX = AF_IPX, afNETLINK = AF_NETLINK, afX25 = AF_X25, afAX25 = AF_AX25, afATMPVC = AF_ATMPVC, afAPPLETALK = AF_APPLETALK, afPACKET = AF_PACKET, afALG = AF_ALG, afUNSPEC = AF_UNSPEC }
	Addres family type. More...

enum	ProtocolNumber { pnHOPOPT = 0, pnICMP = IPPROTO_ICMP, pnICMPV6 = IPPROTO_ICMPV6, pnIGMP = 2, pnGGP = 3, pnIPv4 = 4, pnST = 5, pnTCP = 6, pnCBT = 7, pnEGP = 8, pnIGP = 9, pnBBN_RCC_MON = 10, pnNVP_II = 11, pnPUP = 12, pnARGUS = 13, pnEMCON = 14, pnXNET = 15, pnCHAOS = 16, pnUDP = 17, pnMUX = 18, pnDCN_MEAS = 19, pnHMP = 20, pnPRM = 21, pnXNS_IDP = 22, pnTRUNK_1 = 23, pnTRUNK_2 = 24, pnLEAF_1 = 25, pnLEAF_2 = 26, pnRDP = 27, pnIRTP = 28, pnISO_TP4 = 29, pnNETBLT = 30, pnMFE_NSP = 31, pnMERIT_INP = 32, pnDCCP = 33, pn3PC = 34, pnIDPR = 35, pnXTP = 36, pnDDP = 37, pnIDPR_CMTP = 38 }
	IANA Protocol number. More...

enum	SocketType { stSTREAM = SOCK_STREAM, stDGRAM = SOCK_DGRAM, stSEQPACKET = SOCK_SEQPACKET, stRAW = SOCK_RAW, stRDM = SOCK_RDM, stPACKET = SOCK_PACKET }
	Socket Type type. More...

Public Member Functions
	SocketParams ()
	Default constructor to AF_INET6, SOCK_STREAM, protocol pnHOPOPT. More...

	SocketParams (AddressFamily family)
	Constructor only sets the AddressFamily. More...

	SocketParams (AddressFamily family, SocketType sockettype)
	Constructor sets the AddressFamily and SocketType. More...

	SocketParams (AddressFamily family, SocketType sockettype, ProtocolNumber protocol)
	Constructor sets the AddressFamily, SocketType and ProtocolNumber. More...

std::string	asString () const
	Return the parameters as a string. More...

AddressFamily	getAddressFamily () const
	Get the AddressFamily. More...

ProtocolNumber	getProtocol () const
	Get the ProtocolNumber. More...

SocketType	getSocketType () const
	Get the SocketType. More...

void	setAddressFamily (AddressFamily family)
	Set the AddressFamily. More...

void	setProtocol (ProtocolNumber protocol)
	Set the ProtocolNumber. More...

void	setSocketType (SocketType sockettype)
	Set the SocketType. More...

Static Public Member Functions
static std::string	familyString (AddressFamily family)
	Return the AddressFamily name as a string. More...

static std::string	protocolString (ProtocolNumber protocol)
	Return the ProtocolNumber name as a string. More...

static std::string	socketTypeString (SocketType sockettype)
	Return the SocketType name as a string. More...

Private Attributes
AddressFamily	family_
	The address family. More...

ProtocolNumber	protocol_
	The protocol. More...

SocketType	sockettype_
	The socket type. More...

Detailed Description

Socket parameters - the family (domain), socket type and protocol triplet.

Definition at line 35 of file socketparams.hpp.

Member Enumeration Documentation

◆ AddressFamily

enum dodo::network::SocketParams::AddressFamily

Addres family type.

Definition at line 41 of file socketparams.hpp.

◆ ProtocolNumber

enum dodo::network::SocketParams::ProtocolNumber

IANA Protocol number.

https://www.iana.org/assignments/protocol-numbers/protocol-numbers.xhtml

Definition at line 73 of file socketparams.hpp.

◆ SocketType

enum dodo::network::SocketParams::SocketType

Socket Type type.

Definition at line 59 of file socketparams.hpp.

Constructor & Destructor Documentation

◆ SocketParams() [1/4]

dodo::network::SocketParams::SocketParams ( )

inline

Default constructor to AF_INET6, SOCK_STREAM, protocol pnHOPOPT.

Definition at line 119 of file socketparams.hpp.

◆ SocketParams() [2/4]

dodo::network::SocketParams::SocketParams ( AddressFamily family )

inline

Constructor only sets the AddressFamily.

Parameters

family The AddressFamily.

Definition at line 125 of file socketparams.hpp.

◆ SocketParams() [3/4]

dodo::network::SocketParams::SocketParams	(	AddressFamily	family,
		SocketType	sockettype
	)

inline

Constructor sets the AddressFamily and SocketType.

Parameters

family	The AddressFamily.
sockettype	The SocketType.

Definition at line 132 of file socketparams.hpp.

◆ SocketParams() [4/4]

dodo::network::SocketParams::SocketParams	(	AddressFamily	family,
		SocketType	sockettype,
		ProtocolNumber	protocol
	)

inline

Constructor sets the AddressFamily, SocketType and ProtocolNumber.

Parameters

family	The AddressFamily.
sockettype	The SocketType.
protocol	The ProtocolNumber.

Definition at line 141 of file socketparams.hpp.

Member Function Documentation

◆ asString()

std::string dodo::network::SocketParams::asString ( ) const

inline

Return the parameters as a string.

Returns: The string.

Definition at line 184 of file socketparams.hpp.

References family_, familyString(), protocol_, protocolString(), sockettype_, and socketTypeString().

Referenced by dodo::network::AddrInfoItem::asString().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ familyString()

static std::string dodo::network::SocketParams::familyString ( AddressFamily family )

inlinestatic

Return the AddressFamily name as a string.

Parameters

family The AddressFamily to convert.

Returns: The string.

Definition at line 198 of file socketparams.hpp.

Referenced by asString().

Here is the caller graph for this function:

◆ getAddressFamily()

AddressFamily dodo::network::SocketParams::getAddressFamily ( ) const

inline

Get the AddressFamily.

Returns: The AddressFamily.

Definition at line 148 of file socketparams.hpp.

References family_.

Referenced by dodo::network::BaseSocket::BaseSocket(), and dodo::network::Address::getHostAddrInfo().

Here is the caller graph for this function:

◆ getProtocol()

ProtocolNumber dodo::network::SocketParams::getProtocol ( ) const

inline

Get the ProtocolNumber.

Returns: The ProtocolNumber.

Definition at line 160 of file socketparams.hpp.

References protocol_.

Referenced by dodo::network::BaseSocket::BaseSocket(), and dodo::network::Address::getHostAddrInfo().

Here is the caller graph for this function:

◆ getSocketType()

SocketType dodo::network::SocketParams::getSocketType ( ) const

inline

Get the SocketType.

Returns: The SocketType.

Definition at line 154 of file socketparams.hpp.

References sockettype_.

Referenced by dodo::network::BaseSocket::BaseSocket(), and dodo::network::Address::getHostAddrInfo().

Here is the caller graph for this function:

◆ protocolString()

static std::string dodo::network::SocketParams::protocolString ( ProtocolNumber protocol )

inlinestatic

Return the ProtocolNumber name as a string.

Parameters

protocol The ProtocolNumber to convert.

Returns: The string.

Definition at line 243 of file socketparams.hpp.

Referenced by asString().

Here is the caller graph for this function:

◆ setAddressFamily()

void dodo::network::SocketParams::setAddressFamily ( AddressFamily family )

inline

Set the AddressFamily.

Parameters

family The AddressFamily.

Definition at line 166 of file socketparams.hpp.

References family_.

Referenced by dodo::network::Address::getHostAddrInfo().

Here is the caller graph for this function:

◆ setProtocol()

void dodo::network::SocketParams::setProtocol ( ProtocolNumber protocol )

inline

Set the ProtocolNumber.

Parameters

protocol The ProtocolNumber.

Definition at line 178 of file socketparams.hpp.

References protocol_.

Referenced by dodo::network::Address::getHostAddrInfo().

Here is the caller graph for this function:

◆ setSocketType()

void dodo::network::SocketParams::setSocketType ( SocketType sockettype )

inline

Set the SocketType.

Parameters

sockettype The SocketType.

Definition at line 172 of file socketparams.hpp.

References sockettype_.

Referenced by dodo::network::Address::getHostAddrInfo().

Here is the caller graph for this function:

◆ socketTypeString()

static std::string dodo::network::SocketParams::socketTypeString ( SocketType sockettype )

inlinestatic

Return the SocketType name as a string.

Parameters

sockettype The SocketType to convert.

Returns: The string.

Definition at line 223 of file socketparams.hpp.

Referenced by asString().

Here is the caller graph for this function:

Field Documentation

◆ family_

AddressFamily dodo::network::SocketParams::family_

private

The address family.

Definition at line 270 of file socketparams.hpp.

Referenced by asString(), getAddressFamily(), and setAddressFamily().

◆ protocol_

ProtocolNumber dodo::network::SocketParams::protocol_

private

The protocol.

Definition at line 286 of file socketparams.hpp.

Referenced by asString(), getProtocol(), and setProtocol().

◆ sockettype_

SocketType dodo::network::SocketParams::sockettype_

private

The socket type.

Definition at line 281 of file socketparams.hpp.

Referenced by asString(), getSocketType(), and setSocketType().

The documentation for this class was generated from the following file:

src/include/network/socketparams.hpp
