Interface common to X509 documents. More...

#include <x509cert.hpp>

Inheritance diagram for dodo::network::X509Common:

Data Structures
struct	Identity
	Attributes that together constitute a X509 identity. More...

struct	SAN
	Subject AltName record. More...

Public Types
enum	SANType { SANType::stDNS = GEN_DNS, SANType::stURI = GEN_URI, SANType::stEMAIL = GEN_EMAIL, SANType::stIP = GEN_IPADD }
	The SubjectAltName type. More...

enum	X509Type { X509Type::Unknown, X509Type::PrivateKey, X509Type::PublicKey, X509Type::CertificateSigningRequest, X509Type::Certificate }
	Enumeration of X509 document types. More...

Static Public Member Functions
static X509Type	detectX509Type (const std::string file, std::string &tag)
	Detects a X509 document type from a PEM file. More...

static std::string	SANTypeAsString (const SANType &san_type)
	Convert the SANType name to a string. More...

Static Protected Member Functions
static Identity	parseIdentity (const std::string src)
	Parse a subject or issuer string into an Identity. More...

Private Member Functions
	X509Common ()=delete
	Never construct, interface class. More...

	~X509Common ()=delete
	Never destruct, interface class. More...

Detailed Description

Interface common to X509 documents.

See Secure sockets for details on the role of this class.

Definition at line 39 of file x509cert.hpp.

Member Enumeration Documentation

◆ SANType

enum dodo::network::X509Common::SANType

strong

The SubjectAltName type.

Enumerator
stDNS	A DNS name such as myhost.mydomain.org.
stURI	An URI.
stEMAIL	An email address.
stIP	An IPv4 or IPv6 address.

Definition at line 45 of file x509cert.hpp.

◆ X509Type

enum dodo::network::X509Common::X509Type

strong

Enumeration of X509 document types.

Enumerator
Unknown	Unknown PEM document.
PrivateKey	Private key PEM document (possibly encrypted).
PublicKey	Public key PEM document.
CertificateSigningRequest	CSR PEM document.
Certificate	Certificate PEM document.

Definition at line 165 of file x509cert.hpp.

Constructor & Destructor Documentation

◆ X509Common()

dodo::network::X509Common::X509Common ( )

privatedelete

Never construct, interface class.

◆ ~X509Common()

dodo::network::X509Common::~X509Common ( )

privatedelete

Never destruct, interface class.

Member Function Documentation

◆ detectX509Type()

X509Common::X509Type dodo::network::X509Common::detectX509Type	(	const std::string	file,
		std::string &	tag
	)

static

Detects a X509 document type from a PEM file.

The PEM is not checked on validity, and a result other than X509Type::Unknown does not imply the document is well formed and valid. Note that both private key and encrypted private key PEM files are identified as X509Type::PrivateKey.

Parameters

file	The file name to be content-checked.
tag	Receives the PEM tag (eg 'CERTIFICATE','PRIVATE KEY',..).

Returns: the X509Type.

Definition at line 41 of file x509cert.cpp.

References Certificate, CertificateSigningRequest, PrivateKey, PublicKey, and Unknown.

◆ parseIdentity()

X509Common::Identity dodo::network::X509Common::parseIdentity ( const std::string src )

staticprotected

Parse a subject or issuer string into an Identity.

Parameters

src The identity string

Returns
the Identity.

Definition at line 61 of file x509cert.cpp.

Referenced by dodo::network::X509Certificate::getIssuer(), dodo::network::X509CertificateSigningRequest::getSubject(), and dodo::network::X509Certificate::getSubject().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ SANTypeAsString()

static std::string dodo::network::X509Common::SANTypeAsString ( const SANType & san_type )

inlinestatic

Convert the SANType name to a string.

Parameters

san_type The SANType to convert.

Returns: the string representation.

Definition at line 57 of file x509cert.hpp.

References stDNS, stEMAIL, stIP, and stURI.

The documentation for this class was generated from the following files:

src/include/network/x509cert.hpp
src/lib/network/x509cert.cpp
