Socket for TLS encrypted traffic between trusted endpoints. More...

#include <tlssocket.hpp>

Inheritance diagram for dodo::network::TLSSocket:

Collaboration diagram for dodo::network::TLSSocket:

[legend]

Public Member Functions
	TLSSocket (bool blocking, SocketParams params, TLSContext &tlscontext, const X509Common::SAN &peer_name)
	Construct from scratch. More...

	TLSSocket (int socket, TLSContext &tlscontext, const X509Common::SAN &peer_name)
	Construct from existing socket file descriptor. More...

virtual	~TLSSocket ()
	Destructor. More...

virtual TLSSocket *	accept ()
	Accept a connection. More...

virtual common::SystemError	connect (const Address &address)
	Connect to the Address. More...

X509 *	getPeerCertificate () const
	Get the peer's certificate. More...

std::string	getTLSCurrentCipherName () const
	Return the negotiated cipher name. More...

int	getTLSProtocolVersion () const
	return the negotiated TLS (SSL) protocol version. More...

std::string	getTLSProtocolVersionString () const
	Return the negotiated TLS (SSL) protocol version. More...

bool	operator< (const TLSSocket &socket) const
	Ordering. More...

bool	operator== (const TLSSocket &socket) const
	Identity. More...

virtual common::SystemError	receive (void *buf, ssize_t request, ssize_t &received)
	Receive data. More...

virtual common::SystemError	send (const void *buf, ssize_t len, bool more=false)
	Send data. More...

Public Member Functions inherited from dodo::network::BaseSocket
	BaseSocket ()
	Default constructor creates an invalid socket. More...

	BaseSocket (bool blocking, SocketParams params)
	Construct from SocketParams. More...

	BaseSocket (int socket)
	Construct from a socket descriptor. More...

virtual	~BaseSocket ()
	Destructs this Socket, but does not call close(). More...

common::SystemError	bind (const Address &address)
	Bind the socket to the Address. More...

virtual void	close ()
	Closes the socket, causing the connection, if it exists, to be terminated. More...

virtual std::string	debugDetail () const
	Return debug object state as a string. More...

Address	getAddress () const
	Get the local address for this socket. More...

SocketParams::AddressFamily	getAddressFamily () const
	Get the SocketParams::AddressFamily of the socket. More...

virtual bool	getBlocking () const
	Rerurn true if the socket is operating in blocking mode. More...

int	getFD () const
	Return the socket file descriptor. More...

Address	getPeerAddress () const
	Get the peer (remote) address for this socket. More...

SocketParams::ProtocolNumber	getProtocolNumber () const
	Get the SocketParams::ProtocolNumber of the socket. More...

virtual socklen_t	getReceiveBufSize () const
	Get the maximum buffer length for receive. More...

socklen_t	getSendBufSize () const
	Get the maximum buffer length for send. More...

SocketParams	getSocketParams () const
	Return the SocketParams. More...

SocketParams::SocketType	getSocketType () const
	Get the SocketParams::SocketType of the socket. More...

int	getTTL () const
	Get the Socket TTL (time to live) or the max number of packet hops. More...

bool	isValid () const
	Return true when the socket descriptor is a valid, hence 'possible' descriptor. More...

common::SystemError	listen (const Address &address, int backlog)
	Sets up a listening socket on Address. More...

bool	operator< (const BaseSocket &socket) const
	Add ordering. More...

BaseSocket &	operator= (const BaseSocket &socket)
	Assign from Socket. More...

BaseSocket &	operator= (int socket)
	Assign from existing socket descriptor (int). More...

bool	operator== (const BaseSocket &socket) const
	Add identity. More...

common::SystemError	receiveInt16 (int16_t &value)
	receive an int16_t More...

common::SystemError	receiveInt32 (int32_t &value)
	receive an int32_t More...

common::SystemError	receiveInt64 (int64_t &value)
	receive an int64_t More...

common::SystemError	receiveInt8 (int8_t &value)
	receive an int8_t More...

common::SystemError	receiveLine (std::string &s)
	receive a stream of characters until a ' ' is read (consumed from the socket read buffer but not added to s). More...

common::SystemError	receiveString (std::string &s)
	Receive a std::string as sent by sendString( const std::string& ). More...

common::SystemError	receiveUInt16 (uint16_t &value)
	receive an uint16_t More...

common::SystemError	receiveUInt32 (uint32_t &value)
	receive an uint32_t More...

common::SystemError	receiveUInt64 (uint64_t &value)
	receive an uint64_t More...

common::SystemError	receiveUInt8 (uint8_t &value)
	receive an uint8_t More...

common::SystemError	sendInt16 (int16_t value, bool more=false)
	Send an int16_t. More...

common::SystemError	sendInt32 (int32_t value, bool more=false)
	Send an int32_t. More...

common::SystemError	sendInt64 (int64_t value, bool more=false)
	Send an int64_t. More...

common::SystemError	sendInt8 (int8_t value, bool more=false)
	Send an int8_t. More...

common::SystemError	sendLine (const std::string &s, bool more)
	Sends the std::string terminated by a ' '. More...

common::SystemError	sendString (const std::string &s, bool more=false)
	Sends the std::string as understood by receiveString(). More...

common::SystemError	sendUInt16 (uint16_t value, bool more=false)
	Send an uint16_t. More...

common::SystemError	sendUInt32 (uint32_t value, bool more=false)
	Send an uint32_t. More...

common::SystemError	sendUInt64 (uint64_t value, bool more=false)
	Send an sendUInt64. More...

common::SystemError	sendUInt8 (uint8_t value, bool more=false)
	Send an uint8_t. More...

void	setBlocking (bool blocking)
	Set the Socket blocking mode. More...

void	setReceiveBufSize (socklen_t size)
	Set the size of the receive buffer. More...

void	setReceiveTimeout (double sec)
	Set the receive timeout - a receive will fail if there is no data received before the timeout expires. More...

void	setReUseAddress ()
	Enable the socket to re-use an address when listen/bind is called. More...

void	setReUsePort ()
	Make the socket re-use a port when listen is called. More...

void	setSendBufSize (socklen_t size)
	Set the size of the send buffer. More...

void	setSendTimeout (double sec)
	Set the send timeout - a send will fail if there is no data send before the timeout expires. More...

void	setTCPKeepAlive (bool enable)
	Enable or disable TCP keep-alive on the socket. More...

void	setTCPNoDelay (bool set)
	Set TCP_NODELAY. More...

void	setTTL (int ttl)
	Set the Socket TTL (Time to Live). More...

Public Member Functions inherited from dodo::common::DebugObject
	DebugObject ()
	Default constructor does nothing. More...

virtual	~DebugObject ()
	Destructor does nothing. More...

std::string	debugString () const
	Return the object dump to string. More...

Protected Attributes
X509Common::SAN	peer_name_
	The peer name connected to, for TLS CN and SubjectAltName matching. More...

SSL *	ssl_
	The SSL object. More...

TLSContext &	tlscontext_
	The TLSContext. More...

Protected Attributes inherited from dodo::network::BaseSocket
int	socket_
	The socket file decsriptor. More...

Additional Inherited Members
Protected Member Functions inherited from dodo::common::DebugObject
std::string	debugHeader () const
	Generates a debug header (address of this object and a demangled class name. More...

Detailed Description

Socket for TLS encrypted traffic between trusted endpoints.

Secure sockets

Definition at line 40 of file tlssocket.hpp.

Constructor & Destructor Documentation

◆ TLSSocket() [1/2]

dodo::network::TLSSocket::TLSSocket	(	int	socket,
		TLSContext &	tlscontext,
		const X509Common::SAN &	peer_name
	)

Construct from existing socket file descriptor.

Parameters

socket	The socket file descriptor.
tlscontext	The TLSContext to apply.
peer_name	The peer name to validate against the peer certificate CN and SubjectAltNames. Only used when the tlscontext has pvVerifyFQDN set (and possibly when pvCustom is set).

Definition at line 32 of file tlssocket.cpp.

References ssl_.

Referenced by accept().

Here is the caller graph for this function:

◆ TLSSocket() [2/2]

dodo::network::TLSSocket::TLSSocket	(	bool	blocking,
		SocketParams	params,
		TLSContext &	tlscontext,
		const X509Common::SAN &	peer_name
	)

Construct from scratch.

Parameters

blocking	If true, operate in blocking mode.
params	The SocketParams to apply.
tlscontext	The TLSContext to apply.
peer_name	The peer name to validate against the peer certificate CN and SubjectAltNames. Only used when the tlscontext has pvVerifyFQDN set (and possibly when pvCustom is set).

Definition at line 40 of file tlssocket.cpp.

References dodo::common::getSSLErrors(), dodo::network::TLSContext::isSNIEnabled(), peer_name_, dodo::network::X509Common::SAN::san_name, dodo::network::BaseSocket::socket_, ssl_, and throw_Exception.

Here is the call graph for this function:

◆ ~TLSSocket()

dodo::network::TLSSocket::~TLSSocket ( )

virtual

Destructor.

Definition at line 53 of file tlssocket.cpp.

References ssl_.

Member Function Documentation

◆ accept()

TLSSocket * dodo::network::TLSSocket::accept ( )

virtual

Accept a connection.

Returns: The SystemError.

Implements dodo::network::BaseSocket.

Definition at line 88 of file tlssocket.cpp.

References dodo::common::getSSLErrors(), log_Error, ssl_, dodo::network::X509Common::stDNS, tlscontext_, and TLSSocket().

Here is the call graph for this function:

◆ connect()

common::SystemError dodo::network::TLSSocket::connect ( const Address & address )

virtual

Connect to the Address.

Parameters

address The address to connect to.

Returns: The SystemError code.

Reimplemented from dodo::network::BaseSocket.

Definition at line 57 of file tlssocket.cpp.

Here is the call graph for this function:

◆ getPeerCertificate()

X509 * dodo::network::TLSSocket::getPeerCertificate ( ) const

Get the peer's certificate.

Returns: A pointer to the peer certificate (must not be freed).

Definition at line 101 of file tlssocket.cpp.

References ssl_.

Referenced by connect().

Here is the caller graph for this function:

◆ getTLSCurrentCipherName()

std::string dodo::network::TLSSocket::getTLSCurrentCipherName ( ) const

inline

Return the negotiated cipher name.

This is only meaningful after a connect returned SystemError::ecOK.

Returns: the TLS (SSL) protocol version.

Definition at line 145 of file tlssocket.hpp.

References ssl_.

◆ getTLSProtocolVersion()

int dodo::network::TLSSocket::getTLSProtocolVersion ( ) const

inline

return the negotiated TLS (SSL) protocol version.

This is only meaningfull after a connect returned SystemError::ecOK.

Returns: the TLS (SSL) protocol version.

Definition at line 127 of file tlssocket.hpp.

References ssl_.

◆ getTLSProtocolVersionString()

std::string dodo::network::TLSSocket::getTLSProtocolVersionString ( ) const

inline

Return the negotiated TLS (SSL) protocol version.

This is only meaningful after a connect returned SystemError::ecOK.

Returns: the TLS (SSL) protocol version.

Definition at line 136 of file tlssocket.hpp.

References ssl_.

◆ operator<()

bool dodo::network::TLSSocket::operator< ( const TLSSocket & socket ) const

inline

Ordering.

Parameters

socket The socket to compare to.

Returns: True if this Socket has a smaller socket descriptor than socket.

Definition at line 120 of file tlssocket.hpp.

References dodo::network::BaseSocket::socket_.

◆ operator==()

bool dodo::network::TLSSocket::operator== ( const TLSSocket & socket ) const

inline

Identity.

Parameters

socket The socket to compare to.

Returns: True if both sockets are equal and have the same value in socket_.

Definition at line 113 of file tlssocket.hpp.

References dodo::network::BaseSocket::socket_.

◆ receive()

common::SystemError dodo::network::TLSSocket::receive	(	void *	buf,
		ssize_t	request,
		ssize_t &	received
	)

virtual

Receive data.

Parameters

buf	Buffer to receive in
request	Max bytes to receive in buf
received	Actual received bytes

Returns: The SystemError code.

Implements dodo::network::BaseSocket.

Definition at line 123 of file tlssocket.cpp.

Here is the call graph for this function:

◆ send()

common::SystemError dodo::network::TLSSocket::send	(	const void *	buf,
		ssize_t	len,
		bool	more = `false`
	)

virtual

Send data.

Parameters

buf	Data to send
len	Size of data in buf
more	If true, do not force a send buffer flush, more data will follow

Returns: The SystemError code.

Implements dodo::network::BaseSocket.

Definition at line 105 of file tlssocket.cpp.

References dodo::common::SystemError::ecOK, dodo::common::SystemError::ecSSL_ERROR_NONE, dodo::common::SystemError::ecSSL_ERROR_WANT_ACCEPT, dodo::common::SystemError::ecSSL_ERROR_WANT_CONNECT, dodo::common::SystemError::ecSSL_ERROR_WANT_READ, dodo::common::SystemError::ecSSL_ERROR_WANT_WRITE, dodo::common::SystemError::ecSSL_ERROR_WANT_X509_LOOKUP, dodo::common::SystemError::ecSSL_ERROR_ZERO_RETURN, dodo::common::getSSLErrors(), ssl_, and throw_Exception.

Here is the call graph for this function:

Field Documentation

◆ peer_name_

X509Common::SAN dodo::network::TLSSocket::peer_name_

protected

The peer name connected to, for TLS CN and SubjectAltName matching.

Definition at line 164 of file tlssocket.hpp.

Referenced by connect(), and TLSSocket().

◆ ssl_

SSL* dodo::network::TLSSocket::ssl_

protected

The SSL object.

Definition at line 154 of file tlssocket.hpp.

Referenced by accept(), connect(), getPeerCertificate(), getTLSCurrentCipherName(), getTLSProtocolVersion(), getTLSProtocolVersionString(), receive(), send(), TLSSocket(), and ~TLSSocket().

◆ tlscontext_

TLSContext& dodo::network::TLSSocket::tlscontext_

protected

The TLSContext.

Definition at line 159 of file tlssocket.hpp.

Referenced by accept(), and connect().

The documentation for this class was generated from the following files:

src/include/network/tlssocket.hpp
src/lib/network/tlssocket.cpp

Public Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ TLSSocket() [1/2]

◆ TLSSocket() [2/2]

◆ ~TLSSocket()

Member Function Documentation

◆ accept()

◆ connect()

◆ getPeerCertificate()

◆ getTLSCurrentCipherName()

◆ getTLSProtocolVersion()

◆ getTLSProtocolVersionString()

◆ operator<()

◆ operator==()

◆ receive()

◆ send()

Field Documentation

◆ peer_name_

◆ ssl_

◆ tlscontext_
