Interface to and common implementation of concrete sockets (Socket, TLSSocket). More...

#include <basesocket.hpp>

Inheritance diagram for dodo::network::BaseSocket:

[legend]

Collaboration diagram for dodo::network::BaseSocket:

Public Member Functions
	BaseSocket ()
	Default constructor creates an invalid socket. More...

	BaseSocket (bool blocking, SocketParams params)
	Construct from SocketParams. More...

	BaseSocket (int socket)
	Construct from a socket descriptor. More...

virtual	~BaseSocket ()
	Destructs this Socket, but does not call close(). More...

virtual BaseSocket *	accept ()=0
	Accepts a connection request and return a pointer to a new Socket for the new connection, the caller will own the new Socket object. More...

common::SystemError	bind (const Address &address)
	Bind the socket to the Address. More...

virtual void	close ()
	Closes the socket, causing the connection, if it exists, to be terminated. More...

virtual common::SystemError	connect (const Address &address)
	Connect to the address. More...

virtual std::string	debugDetail () const
	Return debug object state as a string. More...

Address	getAddress () const
	Get the local address for this socket. More...

SocketParams::AddressFamily	getAddressFamily () const
	Get the SocketParams::AddressFamily of the socket. More...

virtual bool	getBlocking () const
	Rerurn true if the socket is operating in blocking mode. More...

int	getFD () const
	Return the socket file descriptor. More...

Address	getPeerAddress () const
	Get the peer (remote) address for this socket. More...

SocketParams::ProtocolNumber	getProtocolNumber () const
	Get the SocketParams::ProtocolNumber of the socket. More...

virtual socklen_t	getReceiveBufSize () const
	Get the maximum buffer length for receive. More...

socklen_t	getSendBufSize () const
	Get the maximum buffer length for send. More...

SocketParams	getSocketParams () const
	Return the SocketParams. More...

SocketParams::SocketType	getSocketType () const
	Get the SocketParams::SocketType of the socket. More...

int	getTTL () const
	Get the Socket TTL (time to live) or the max number of packet hops. More...

bool	isValid () const
	Return true when the socket descriptor is a valid, hence 'possible' descriptor. More...

common::SystemError	listen (const Address &address, int backlog)
	Sets up a listening socket on Address. More...

bool	operator< (const BaseSocket &socket) const
	Add ordering. More...

BaseSocket &	operator= (const BaseSocket &socket)
	Assign from Socket. More...

BaseSocket &	operator= (int socket)
	Assign from existing socket descriptor (int). More...

bool	operator== (const BaseSocket &socket) const
	Add identity. More...

virtual common::SystemError	receive (void *buf, ssize_t request, ssize_t &received)=0
	Receive bytes from the socket. More...

common::SystemError	receiveInt16 (int16_t &value)
	receive an int16_t More...

common::SystemError	receiveInt32 (int32_t &value)
	receive an int32_t More...

common::SystemError	receiveInt64 (int64_t &value)
	receive an int64_t More...

common::SystemError	receiveInt8 (int8_t &value)
	receive an int8_t More...

common::SystemError	receiveLine (std::string &s)
	receive a stream of characters until a ' ' is read (consumed from the socket read buffer but not added to s). More...

common::SystemError	receiveString (std::string &s)
	Receive a std::string as sent by sendString( const std::string& ). More...

common::SystemError	receiveUInt16 (uint16_t &value)
	receive an uint16_t More...

common::SystemError	receiveUInt32 (uint32_t &value)
	receive an uint32_t More...

common::SystemError	receiveUInt64 (uint64_t &value)
	receive an uint64_t More...

common::SystemError	receiveUInt8 (uint8_t &value)
	receive an uint8_t More...

virtual common::SystemError	send (const void *buf, ssize_t len, bool more=false)=0
	Send bytes on the socket. More...

common::SystemError	sendInt16 (int16_t value, bool more=false)
	Send an int16_t. More...

common::SystemError	sendInt32 (int32_t value, bool more=false)
	Send an int32_t. More...

common::SystemError	sendInt64 (int64_t value, bool more=false)
	Send an int64_t. More...

common::SystemError	sendInt8 (int8_t value, bool more=false)
	Send an int8_t. More...

common::SystemError	sendLine (const std::string &s, bool more)
	Sends the std::string terminated by a ' '. More...

common::SystemError	sendString (const std::string &s, bool more=false)
	Sends the std::string as understood by receiveString(). More...

common::SystemError	sendUInt16 (uint16_t value, bool more=false)
	Send an uint16_t. More...

common::SystemError	sendUInt32 (uint32_t value, bool more=false)
	Send an uint32_t. More...

common::SystemError	sendUInt64 (uint64_t value, bool more=false)
	Send an sendUInt64. More...

common::SystemError	sendUInt8 (uint8_t value, bool more=false)
	Send an uint8_t. More...

void	setBlocking (bool blocking)
	Set the Socket blocking mode. More...

void	setReceiveBufSize (socklen_t size)
	Set the size of the receive buffer. More...

void	setReceiveTimeout (double sec)
	Set the receive timeout - a receive will fail if there is no data received before the timeout expires. More...

void	setReUseAddress ()
	Enable the socket to re-use an address when listen/bind is called. More...

void	setReUsePort ()
	Make the socket re-use a port when listen is called. More...

void	setSendBufSize (socklen_t size)
	Set the size of the send buffer. More...

void	setSendTimeout (double sec)
	Set the send timeout - a send will fail if there is no data send before the timeout expires. More...

void	setTCPKeepAlive (bool enable)
	Enable or disable TCP keep-alive on the socket. More...

void	setTCPNoDelay (bool set)
	Set TCP_NODELAY. More...

void	setTTL (int ttl)
	Set the Socket TTL (Time to Live). More...

Public Member Functions inherited from dodo::common::DebugObject
	DebugObject ()
	Default constructor does nothing. More...

virtual	~DebugObject ()
	Destructor does nothing. More...

std::string	debugString () const
	Return the object dump to string. More...

Protected Attributes
int	socket_
	The socket file decsriptor. More...

Additional Inherited Members
Protected Member Functions inherited from dodo::common::DebugObject
std::string	debugHeader () const
	Generates a debug header (address of this object and a demangled class name. More...

Detailed Description

Interface to and common implementation of concrete sockets (Socket, TLSSocket).

Definition at line 36 of file basesocket.hpp.

Constructor & Destructor Documentation

◆ BaseSocket() [1/3]

dodo::network::BaseSocket::BaseSocket ( )

Default constructor creates an invalid socket.

Definition at line 31 of file basesocket.cpp.

References socket_.

◆ BaseSocket() [2/3]

dodo::network::BaseSocket::BaseSocket ( int socket )

Construct from a socket descriptor.

Parameters

socket The socket file descriptor.

Definition at line 35 of file basesocket.cpp.

References socket_.

◆ BaseSocket() [3/3]

dodo::network::BaseSocket::BaseSocket	(	bool	blocking,
		SocketParams	params
	)

explicit

Construct from SocketParams.

Parameters

blocking	If true, create the socket in blocking mode.
params	The SocketParams to use.

Definition at line 39 of file basesocket.cpp.

References dodo::network::SocketParams::getAddressFamily(), dodo::network::SocketParams::getProtocol(), dodo::network::SocketParams::getSocketType(), setBlocking(), setTCPNoDelay(), socket_, and throw_SystemExceptionObject.

Here is the call graph for this function:

◆ ~BaseSocket()

virtual dodo::network::BaseSocket::~BaseSocket ( )

inlinevirtual

Destructs this Socket, but does not call close().

Definition at line 60 of file basesocket.hpp.

Member Function Documentation

◆ accept()

virtual BaseSocket* dodo::network::BaseSocket::accept ( )

pure virtual

Accepts a connection request and return a pointer to a new Socket for the new connection, the caller will own the new Socket object.

Returns: The accepted socket.

Implemented in dodo::network::Socket, and dodo::network::TLSSocket.

Referenced by dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ bind()

common::SystemError dodo::network::BaseSocket::bind ( const Address & address )

Bind the socket to the Address.

Parameters

address The address to bind to.

Returns

SystemError::ecOK or

SystemError::ecEACCES
SystemError::ecEADDRINUSE
SystemError::ecEBADF
SystemError::ecEINVAL
SystemError::ecENOTSOCK

Definition at line 103 of file basesocket.cpp.

References dodo::network::Address::addr_, dodo::network::Address::asString(), dodo::common::SystemError::ecEACCES, dodo::common::SystemError::ecEADDRINUSE, dodo::common::SystemError::ecOK, socket_, and throw_SystemExceptionObject.

Referenced by listen().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ close()

void dodo::network::BaseSocket::close ( )

virtual

Closes the socket, causing the connection, if it exists, to be terminated.

Definition at line 71 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by dodo::network::TCPListener::closeSocket(), and dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ connect()

common::SystemError dodo::network::BaseSocket::connect ( const Address & address )

virtual

Connect to the address.

These common::SystemError may be returned:

SystemError::ecOK
SystemError::ecEACCES
SystemError::ecEADDRINUSE
SystemError::ecEADDRNOTAVAIL
SystemError::ecEALREADY
SystemError::ecECONNREFUSED
SystemError::ecEINPROGRESS
SystemError::ecEISCONN
SystemError::ecENETUNREACH
SystemError::ecETIMEDOUT

In case the system returns other system errors on connect, a common::Exception is thrown.

Parameters

address The address to connect to.

Returns: The SystemError

Reimplemented in dodo::network::TLSSocket.

Definition at line 52 of file basesocket.cpp.

References dodo::common::SystemError::ecEACCES, dodo::common::SystemError::ecEADDRINUSE, dodo::common::SystemError::ecEADDRNOTAVAIL, dodo::common::SystemError::ecEALREADY, dodo::common::SystemError::ecECONNREFUSED, dodo::common::SystemError::ecEINPROGRESS, dodo::common::SystemError::ecEISCONN, dodo::common::SystemError::ecENETUNREACH, dodo::common::SystemError::ecETIMEDOUT, dodo::common::SystemError::ecOK, dodo::network::Address::getAddress(), socket_, and throw_SystemExceptionObject.

Referenced by dodo::network::TLSSocket::connect().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ debugDetail()

std::string dodo::network::BaseSocket::debugDetail ( ) const

virtual

Return debug object state as a string.

Returns: The string.

Reimplemented from dodo::common::DebugObject.

Definition at line 46 of file basesocket.cpp.

References socket_.

◆ getAddress()

Address dodo::network::BaseSocket::getAddress ( ) const

Get the local address for this socket.

Returns: The local Address.

Definition at line 236 of file basesocket.cpp.

References socket_.

◆ getAddressFamily()

SocketParams::AddressFamily dodo::network::BaseSocket::getAddressFamily ( ) const

Get the SocketParams::AddressFamily of the socket.

Returns: The address family.

Definition at line 244 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by getSocketParams(), and getTTL().

Here is the caller graph for this function:

◆ getBlocking()

bool dodo::network::BaseSocket::getBlocking ( ) const

virtual

Rerurn true if the socket is operating in blocking mode.

Returns: The mode.

Definition at line 125 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by receiveString(), sendString(), and dodo::network::SocketReadBuffer::SocketReadBuffer().

Here is the caller graph for this function:

◆ getFD()

int dodo::network::BaseSocket::getFD ( ) const

inline

Return the socket file descriptor.

Returns: The socket descriptor.

Definition at line 121 of file basesocket.hpp.

References socket_.

Referenced by dodo::network::TCPListener::closeSocket(), dodo::network::TCPListener::pollAdd(), dodo::network::TCPListener::pollDel(), dodo::network::TCPListener::pollMod(), dodo::network::TCPListener::popWork(), dodo::network::TCPListener::pushWork(), dodo::network::TCPConnectionData::readBuffer(), dodo::network::TCPListener::releaseWork(), dodo::network::TCPServer::run(), and dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ getPeerAddress()

Address dodo::network::BaseSocket::getPeerAddress ( ) const

Get the peer (remote) address for this socket.

Returns: The peer Address.

Definition at line 273 of file basesocket.cpp.

References socket_.

Referenced by dodo::network::TCPServer::run(), and dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ getProtocolNumber()

SocketParams::ProtocolNumber dodo::network::BaseSocket::getProtocolNumber ( ) const

Get the SocketParams::ProtocolNumber of the socket.

Returns: The ProtocolNumber.

Definition at line 260 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by getSocketParams().

Here is the caller graph for this function:

◆ getReceiveBufSize()

socklen_t dodo::network::BaseSocket::getReceiveBufSize ( ) const

virtual

Get the maximum buffer length for receive.

Returns: The receive buffer size.

See also: setReceiveBufSize()

Definition at line 177 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by receiveString().

Here is the caller graph for this function:

◆ getSendBufSize()

socklen_t dodo::network::BaseSocket::getSendBufSize ( ) const

Get the maximum buffer length for send.

Returns: The send buffer size.

See also: setSendBufSize

Definition at line 169 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

◆ getSocketParams()

SocketParams dodo::network::BaseSocket::getSocketParams ( ) const

Return the SocketParams.

See also: getAddressFamily(), getSocketType(), getProtocolNumber()

Returns: the SocketParams.

Definition at line 268 of file basesocket.cpp.

References getAddressFamily(), getProtocolNumber(), and getSocketType().

Here is the call graph for this function:

◆ getSocketType()

SocketParams::SocketType dodo::network::BaseSocket::getSocketType ( ) const

Get the SocketParams::SocketType of the socket.

Returns: The SocketType.

Definition at line 252 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by getSocketParams().

Here is the caller graph for this function:

◆ getTTL()

int dodo::network::BaseSocket::getTTL ( ) const

Get the Socket TTL (time to live) or the max number of packet hops.

Returns: The current socket TTL value.

Definition at line 185 of file basesocket.cpp.

References getAddressFamily(), socket_, and throw_SystemExceptionObject.

Here is the call graph for this function:

◆ isValid()

bool dodo::network::BaseSocket::isValid ( ) const

inline

Return true when the socket descriptor is a valid, hence 'possible' descriptor.

A valid decsriptor does not have to be open/connected or even correct - a valid decsriptor is not -1.

Returns: true of the socket is a valid descriptor ( >= 0 );

Definition at line 128 of file basesocket.hpp.

References socket_.

Referenced by dodo::network::TCPListener::run(), setBlocking(), and setReUseAddress().

Here is the caller graph for this function:

◆ listen()

common::SystemError dodo::network::BaseSocket::listen	(	const Address &	address,
		int	backlog
	)

Sets up a listening socket on Address.

Parameters

address	The Address (including a port) to listen on.
backlog	The size of the queue used to cache pending connections.

Returns

A common::SystemError, if not ecOK

or one of the common::SystemError returned by bind( const Address &address ).

Definition at line 89 of file basesocket.cpp.

References dodo::network::Address::asString(), bind(), dodo::common::SystemError::ecEADDRINUSE, dodo::common::SystemError::ecOK, socket_, and throw_SystemExceptionObject.

Referenced by dodo::network::TCPListener::construct().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator<()

bool dodo::network::BaseSocket::operator< ( const BaseSocket & socket ) const

inline

Add ordering.

Parameters

socket The socket to compare to.

Returns: True if this Socket has a smaller socket descriptor than socket.

Definition at line 281 of file basesocket.hpp.

References socket_.

◆ operator=() [1/2]

BaseSocket & dodo::network::BaseSocket::operator= ( const BaseSocket & socket )

Assign from Socket.

Parameters

socket The Socket to assign/copy to this Socket.

Returns: This Socket.

Definition at line 84 of file basesocket.cpp.

References socket_.

◆ operator=() [2/2]

BaseSocket & dodo::network::BaseSocket::operator= ( int socket )

Assign from existing socket descriptor (int).

Parameters

socket The socket value to assign to this Socket.

Returns: This Socket.

Definition at line 79 of file basesocket.cpp.

References socket_.

◆ operator==()

bool dodo::network::BaseSocket::operator== ( const BaseSocket & socket ) const

inline

Add identity.

Parameters

socket The socket to compare to.

Returns: True if both sockets are equal and have the sxame value of socket_.

Definition at line 274 of file basesocket.hpp.

References socket_.

◆ receive()

virtual common::SystemError dodo::network::BaseSocket::receive	(	void *	buf,
		ssize_t	request,
		ssize_t &	received
	)

pure virtual

Receive bytes from the socket.

Parameters

buf	Put bytes received here
request	The maximum number of bytes to receive
received	The number of bytes received

Returns: The SystemError.

Implemented in dodo::network::Socket, and dodo::network::TLSSocket.

Referenced by dodo::network::TCPConnectionData::readBuffer(), receiveInt16(), receiveInt32(), receiveInt64(), receiveInt8(), receiveLine(), receiveString(), receiveUInt16(), receiveUInt32(), receiveUInt64(), receiveUInt8(), and dodo::network::SocketReadBuffer::underflow().

Here is the caller graph for this function:

◆ receiveInt16()

common::SystemError dodo::network::BaseSocket::receiveInt16 ( int16_t & value )

receive an int16_t

Parameters

value The value received.

Returns: Same as receive( void* buf, ssize_t request, ssize_t &received )

See also: sendInt16( int16_t )*

Definition at line 349 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, and receive().

Here is the call graph for this function:

◆ receiveInt32()

common::SystemError dodo::network::BaseSocket::receiveInt32 ( int32_t & value )

receive an int32_t

Parameters

value The value received.

Returns: Same as receive( void* buf, ssize_t request, ssize_t &received )

See also: sendInt32( int32_t )*

Definition at line 391 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, and receive().

Here is the call graph for this function:

◆ receiveInt64()

common::SystemError dodo::network::BaseSocket::receiveInt64 ( int64_t & value )

receive an int64_t

Parameters

value The value received.

Returns: Same as receive( void* buf, ssize_t request, ssize_t &received )

See also: sendInt64( int64_t )*

Definition at line 433 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, and receive().

Here is the call graph for this function:

◆ receiveInt8()

common::SystemError dodo::network::BaseSocket::receiveInt8 ( int8_t & value )

receive an int8_t

Parameters

value The value received.

Returns: Same as receive( void* buf, ssize_t request, ssize_t &received )

See also: sendInt8( int8_t )*

Definition at line 328 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, and receive().

Here is the call graph for this function:

◆ receiveLine()

common::SystemError dodo::network::BaseSocket::receiveLine ( std::string & s )

receive a stream of characters until a '
' is read (consumed from the socket read buffer but not added to s).

Parameters

s	receives the read string.

Returns: The SystemError.

Definition at line 488 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, and receive().

Here is the call graph for this function:

◆ receiveString()

common::SystemError dodo::network::BaseSocket::receiveString ( std::string & s )

Receive a std::string as sent by sendString( const std::string& ).

Parameters

s	The string to receive into.

Returns: Same as receive( void* buf, ssize_t request, ssize_t &received )

Definition at line 459 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, getBlocking(), getReceiveBufSize(), receive(), receiveUInt64(), and throw_ExceptionObject.

Here is the call graph for this function:

◆ receiveUInt16()

common::SystemError dodo::network::BaseSocket::receiveUInt16 ( uint16_t & value )

receive an uint16_t

Parameters

value The value received.

Returns: Same as receive( void* buf, ssize_t request, ssize_t &received )

See also: sendUInt16( uint16_t )

Definition at line 307 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, and receive().

Here is the call graph for this function:

◆ receiveUInt32()

common::SystemError dodo::network::BaseSocket::receiveUInt32 ( uint32_t & value )

receive an uint32_t

Parameters

value The value received.

Returns: Same as receive( void* buf, ssize_t request, ssize_t &received )

See also: sendUInt32( uint32_t )

Definition at line 370 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, and receive().

Here is the call graph for this function:

◆ receiveUInt64()

common::SystemError dodo::network::BaseSocket::receiveUInt64 ( uint64_t & value )

receive an uint64_t

Parameters

value The value received.

Returns: Same as receive( void* buf, ssize_t request, ssize_t &received )

See also: sendUInt64( uint64_t )*

Definition at line 412 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, and receive().

Referenced by receiveString().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ receiveUInt8()

common::SystemError dodo::network::BaseSocket::receiveUInt8 ( uint8_t & value )

receive an uint8_t

Parameters

value The value received.

Returns: Same as receive( void* buf, ssize_t request, ssize_t &received )

See also: sendUInt8( uint8_t )

Definition at line 286 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, and receive().

Here is the call graph for this function:

◆ send()

virtual common::SystemError dodo::network::BaseSocket::send	(	const void *	buf,
		ssize_t	len,
		bool	more = `false`
	)

pure virtual

Send bytes on the socket.

Parameters

buf	Take bytes from here
len	The number of bytes.
more	Set to true if more is to come (increases packet filling efficiency when accurate).

Returns: The SystemError.

Implemented in dodo::network::Socket, and dodo::network::TLSSocket.

Referenced by dodo::network::protocol::http::HTTPRequest::send(), dodo::network::protocol::http::HTTPResponse::send(), sendInt16(), sendInt32(), sendInt64(), sendInt8(), sendLine(), sendString(), sendUInt16(), sendUInt32(), sendUInt64(), sendUInt8(), and dodo::network::protocol::http::HTTPRequest::write().

Here is the caller graph for this function:

◆ sendInt16()

common::SystemError dodo::network::BaseSocket::sendInt16	(	int16_t	value,
		bool	more = `false`
	)

Send an int16_t.

Parameters

value	The value to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

See also: receiveInt16( int16_t& )

Definition at line 344 of file basesocket.cpp.

References send().

Here is the call graph for this function:

◆ sendInt32()

common::SystemError dodo::network::BaseSocket::sendInt32	(	int32_t	value,
		bool	more = `false`
	)

Send an int32_t.

Parameters

value	The value to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

See also: receiveInt32( int32_t& )

Definition at line 386 of file basesocket.cpp.

References send().

Here is the call graph for this function:

◆ sendInt64()

common::SystemError dodo::network::BaseSocket::sendInt64	(	int64_t	value,
		bool	more = `false`
	)

Send an int64_t.

Parameters

value	The value to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

See also: receiveInt64( int64_t& )

Definition at line 428 of file basesocket.cpp.

References send().

Here is the call graph for this function:

◆ sendInt8()

common::SystemError dodo::network::BaseSocket::sendInt8	(	int8_t	value,
		bool	more = `false`
	)

Send an int8_t.

Parameters

value	The value to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

See also: receiveInt8( int8_t& )

Definition at line 323 of file basesocket.cpp.

References send().

Here is the call graph for this function:

◆ sendLine()

common::SystemError dodo::network::BaseSocket::sendLine	(	const std::string &	s,
		bool	more
	)

Sends the std::string terminated by a '
'.

Parameters

s	The string to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

Definition at line 480 of file basesocket.cpp.

References send().

Here is the call graph for this function:

◆ sendString()

common::SystemError dodo::network::BaseSocket::sendString	(	const std::string &	s,
		bool	more = `false`
	)

Sends the std::string as understood by receiveString().

The send prefixes the string length in an uint64_t, the number of bytes (characters) that follow.

Parameters

s	The string to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

Definition at line 449 of file basesocket.cpp.

References dodo::common::SystemError::ecOK, getBlocking(), send(), sendUInt64(), and throw_Exception.

Here is the call graph for this function:

◆ sendUInt16()

common::SystemError dodo::network::BaseSocket::sendUInt16	(	uint16_t	value,
		bool	more = `false`
	)

Send an uint16_t.

Parameters

value	The value to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

See also: receiveUInt16( uint16_t& )

Definition at line 302 of file basesocket.cpp.

References send().

Here is the call graph for this function:

◆ sendUInt32()

common::SystemError dodo::network::BaseSocket::sendUInt32	(	uint32_t	value,
		bool	more = `false`
	)

Send an uint32_t.

Parameters

value	The value to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

See also: receiveUInt32( uint32_t& )

Definition at line 365 of file basesocket.cpp.

References send().

Here is the call graph for this function:

◆ sendUInt64()

common::SystemError dodo::network::BaseSocket::sendUInt64	(	uint64_t	value,
		bool	more = `false`
	)

Send an sendUInt64.

Parameters

value	The value to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

See also: receiveUInt64( uint64_t& )

Definition at line 407 of file basesocket.cpp.

References send().

Referenced by sendString().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ sendUInt8()

common::SystemError dodo::network::BaseSocket::sendUInt8	(	uint8_t	value,
		bool	more = `false`
	)

Send an uint8_t.

Parameters

value	The value to send.
more	If true, the caller indicates that more data will follow.

Returns: Same as send( const void* buf, ssize_t len )

See also: receiveUInt8( uint8_t& )

Definition at line 281 of file basesocket.cpp.

References send().

Here is the call graph for this function:

◆ setBlocking()

void dodo::network::BaseSocket::setBlocking ( bool blocking )

Set the Socket blocking mode.

Parameters

blocking Blocking if true.

Definition at line 131 of file basesocket.cpp.

References isValid(), socket_, throw_Exception, and throw_SystemExceptionObject.

Referenced by BaseSocket(), dodo::network::TCPListener::construct(), and dodo::network::TCPListener::run().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ setReceiveBufSize()

void dodo::network::BaseSocket::setReceiveBufSize ( socklen_t size )

Set the size of the receive buffer.

Linux will (at least) double the memory for socket accounting purposes. If size < system minimum size, the system will set the latter.

See also: setSendBufSize( socklen_t size )

Parameters

size	The size to set the receive buffer to.

Definition at line 204 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by dodo::network::TCPListener::construct().

Here is the caller graph for this function:

◆ setReceiveTimeout()

void dodo::network::BaseSocket::setReceiveTimeout ( double sec )

Set the receive timeout - a receive will fail if there is no data received before the timeout expires.

Note that the default is 0 seconds, meaning no timeout / wait forever.

Parameters

sec	Timeout value, in seconds, fractions allowed.

Definition at line 209 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by dodo::network::TCPListener::construct(), and dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ setReUseAddress()

void dodo::network::BaseSocket::setReUseAddress ( )

Enable the socket to re-use an address when listen/bind is called.

In transit TCP messages sent to a server previously listening on this address will not be picked up by the re-used address.

See also: setReUsePort()

Definition at line 148 of file basesocket.cpp.

References isValid(), socket_, throw_Exception, and throw_SystemExceptionObject.

Referenced by dodo::network::TCPListener::construct().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ setReUsePort()

void dodo::network::BaseSocket::setReUsePort ( )

Make the socket re-use a port when listen is called.

See also: setReUseAddress()

Definition at line 159 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by dodo::network::TCPListener::construct().

Here is the caller graph for this function:

◆ setSendBufSize()

void dodo::network::BaseSocket::setSendBufSize ( socklen_t size )

Set the size of the send buffer.

Linux will (at least) double the memory for socket accounting purposes. If size < system minimum size or size > system maximum size, the system will silently overrule. Also note that getSendBufSize() and getReceiveBufSize() return the size of the kernel send buffer divided by two, as the Linux man 7 socket states: "...Linux assumes that half of the send/receive buffer is used for internal kernel structures;" So getSendBufSize() and getReceiveBufSize() return the values from a programmer perspective - it is the number of bytes the programmer can actually send or receive in one go

Socket s;
s.setSendBufSize(8192);          // kernel has set it to 16384
int n = s.getSendBufSize();      // n = 8192
char buffer[s.getSendBufSize()]; // which is what you asked for and will fit

Parameters

size	The size to set the send buffer to.

Definition at line 199 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by dodo::network::TCPListener::construct().

Here is the caller graph for this function:

◆ setSendTimeout()

void dodo::network::BaseSocket::setSendTimeout ( double sec )

Set the send timeout - a send will fail if there is no data send before the timeout expires.

Note that the default is 0 seconds, meaning no timeout / wait forever.

Parameters

sec	Timeout value, in seconds, fractions allowed.

Definition at line 219 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Referenced by dodo::network::TCPListener::construct(), and dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ setTCPKeepAlive()

void dodo::network::BaseSocket::setTCPKeepAlive ( bool enable )

Enable or disable TCP keep-alive on the socket.

This might be useful to keep connections ope that run through a firewall that disconnects connections that are idle. Note that keep-alive itself is configured through the Linux kernel. Note that enabling keep-alive will not change the behavior of the socket from a developers perspective but ti does incur a bit of network overhead.

Parameters

enable If true enable, otherwise disable.

Definition at line 120 of file basesocket.cpp.

References socket_.

Referenced by dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ setTCPNoDelay()

void dodo::network::BaseSocket::setTCPNoDelay ( bool set )

Set TCP_NODELAY.

If true, disable Nagle's algorithm.

Parameters

set	If true, set TCP_NODELAY.

Definition at line 115 of file basesocket.cpp.

References socket_.

Referenced by BaseSocket(), and dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ setTTL()

void dodo::network::BaseSocket::setTTL ( int ttl )

Set the Socket TTL (Time to Live).

Parameters

ttl	The ttl value to set.

See also: getTTL()

Definition at line 229 of file basesocket.cpp.

References socket_, and throw_SystemExceptionObject.

Field Documentation

◆ socket_

int dodo::network::BaseSocket::socket_

protected

The socket file decsriptor.

Definition at line 503 of file basesocket.hpp.

Referenced by dodo::network::Socket::accept(), BaseSocket(), bind(), close(), connect(), dodo::network::TLSSocket::connect(), debugDetail(), getAddress(), getAddressFamily(), getBlocking(), getFD(), getPeerAddress(), getProtocolNumber(), getReceiveBufSize(), getSendBufSize(), getSocketType(), getTTL(), isValid(), listen(), dodo::network::TLSSocket::operator<(), operator<(), operator=(), dodo::network::TLSSocket::operator==(), operator==(), dodo::network::Socket::receive(), dodo::network::Socket::send(), dodo::network::Socket::sendTo(), setBlocking(), setReceiveBufSize(), setReceiveTimeout(), setReUseAddress(), setReUsePort(), setSendBufSize(), setSendTimeout(), setTCPKeepAlive(), setTCPNoDelay(), setTTL(), and dodo::network::TLSSocket::TLSSocket().

The documentation for this class was generated from the following files:

src/include/network/basesocket.hpp
src/lib/network/basesocket.cpp

Public Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ BaseSocket() [1/3]

◆ BaseSocket() [2/3]

◆ BaseSocket() [3/3]

◆ ~BaseSocket()

Member Function Documentation

◆ accept()

◆ bind()

◆ close()

◆ connect()

◆ debugDetail()

◆ getAddress()

◆ getAddressFamily()

◆ getBlocking()

◆ getFD()

◆ getPeerAddress()

◆ getProtocolNumber()

◆ getReceiveBufSize()

◆ getSendBufSize()

◆ getSocketParams()

◆ getSocketType()

◆ getTTL()

◆ isValid()

◆ listen()

◆ operator<()

◆ operator=() [1/2]

◆ operator=() [2/2]

◆ operator==()

◆ receive()

◆ receiveInt16()

◆ receiveInt32()

◆ receiveInt64()

◆ receiveInt8()

◆ receiveLine()

◆ receiveString()

◆ receiveUInt16()

◆ receiveUInt32()

◆ receiveUInt64()

◆ receiveUInt8()

◆ send()

◆ sendInt16()

◆ sendInt32()

◆ sendInt64()

◆ sendInt8()

◆ sendLine()

◆ sendString()

◆ sendUInt16()

◆ sendUInt32()

◆ sendUInt64()

◆ sendUInt8()

◆ setBlocking()

◆ setReceiveBufSize()

◆ setReceiveTimeout()

◆ setReUseAddress()

◆ setReUsePort()

◆ setSendBufSize()

◆ setSendTimeout()

◆ setTCPKeepAlive()

◆ setTCPNoDelay()

◆ setTTL()

Field Documentation

◆ socket_
