Generic HTTP fragment, either a complete (such as HTTPRequest) or incomplete HTTP fragment (ssuch as a HTTPRequest::HTTPRequestLine) . More...

#include <httpfragment.hpp>

Inheritance diagram for dodo::network::protocol::http::HTTPFragment:

[legend]

Data Structures
struct	ParseResult
	Used to convey parsing succces. More...

Public Types
enum	ParseError : unsigned int { peOk = 0, peIncomplete, peSystemError, peExpectCRLF, peUnFinishedToken, peExpectingHeaderColon, peInvalidHeaderFieldValue, peInvalidHeaderListEnd, peInvalidMethod, peInvalidHTTPVersion, peInvalidRequestLine, peInvalidContentLength, peUnexpectedBody, peInvalidTransferEncoding, peInvalidChunkHex, peInvalidLastChunk, peExpectingUnsignedInt }
	Parse results returned by the parse functions. More...

Public Member Functions
virtual std::string	asString () const =0
	Convert the HTTPFragment in a HTTP protocol string. More...

virtual ParseResult	parse (VirtualReadBuffer &buffer)=0
	Read a complete HTTPFragment from a VirtualReadBuffer. More...

Static Public Member Functions
static std::string	getParseResultAsString (ParseError error)
	Return the string description of a ParseError. More...

Detailed Description

Generic HTTP fragment, either a complete (such as HTTPRequest) or incomplete HTTP fragment (ssuch as a HTTPRequest::HTTPRequestLine) .

Descendant classes implement ParseResult parse( VirtualReadBuffer& buffer ) to extract a complete HTTP fragment. Note that the buffer is expected to be blocking on reads, if the HTTPFragment expects more data it will wait and in case of a read timeout, fail. If the parse fails due to incomplete data within the timeout, the ParseResult return value is { peSystemError, common::SystemError::ecEAGAIN }.

Definition at line 45 of file httpfragment.hpp.

Member Enumeration Documentation

◆ ParseError

enum dodo::network::protocol::http::HTTPFragment::ParseError : unsigned int

Parse results returned by the parse functions.

Enumerator
peOk	Ok.
peIncomplete	Not an error, but more data is expected to complete.
peSystemError	The parse failed due to system error SocketReadBuffer::getLastError()
peExpectCRLF	A CR was not followed by an LF.
peUnFinishedToken	A token is being parsed but is ending erroneously.
peExpectingHeaderColon	A header field name was read, but no colon found after it.
peInvalidHeaderFieldValue	A header field value was being read, but it is invalid.
peInvalidHeaderListEnd	A header list is not ending properly.
peInvalidMethod	An invalid method was specified in the request line.
peInvalidHTTPVersion	An invalid HTTP version was specified in the request line.
peInvalidRequestLine	The request line is invalid.
peInvalidContentLength	The content length does not match the message body size.
peUnexpectedBody	A message body is present but should not be there.
peInvalidTransferEncoding	The specified transfer-encoding header is invalid.
peInvalidChunkHex	The hex chunk size is invalid.
peInvalidLastChunk	The last chunk does not have size 0.
peExpectingUnsignedInt	An unsigned int was expected.

Definition at line 51 of file httpfragment.hpp.

Member Function Documentation

◆ asString()

virtual std::string dodo::network::protocol::http::HTTPFragment::asString ( ) const

pure virtual

Convert the HTTPFragment in a HTTP protocol string.

Returns: The HTTPFragment as a string.

Implemented in dodo::network::protocol::http::HTTPResponse, dodo::network::protocol::http::HTTPRequest, dodo::network::protocol::http::HTTPResponse::HTTPResponseLine, dodo::network::protocol::http::HTTPRequest::HTTPRequestLine, and dodo::network::protocol::http::HTTPVersion.

◆ getParseResultAsString()

std::string dodo::network::protocol::http::HTTPFragment::getParseResultAsString ( ParseError error )

static

Return the string description of a ParseError.

Parameters

error The ParseError to describe.

Returns: The ParseError description.

Definition at line 37 of file httpfragment.cpp.

References peExpectCRLF, peExpectingHeaderColon, peExpectingUnsignedInt, peIncomplete, peInvalidChunkHex, peInvalidContentLength, peInvalidHeaderFieldValue, peInvalidHeaderListEnd, peInvalidHTTPVersion, peInvalidLastChunk, peInvalidMethod, peInvalidRequestLine, peInvalidTransferEncoding, peOk, peSystemError, peUnexpectedBody, and peUnFinishedToken.

Referenced by dodo::network::protocol::http::HTTPFragment::ParseResult::asString().

Here is the caller graph for this function:

◆ parse()

virtual ParseResult dodo::network::protocol::http::HTTPFragment::parse ( VirtualReadBuffer & buffer )

pure virtual

Read a complete HTTPFragment from a VirtualReadBuffer.

Parameters

buffer the VirtualReadBuffer to get characters from.

Returns: The ParseError.

Implemented in dodo::network::protocol::http::HTTPResponse::HTTPResponseLine, dodo::network::protocol::http::HTTPRequest, dodo::network::protocol::http::HTTPRequest::HTTPRequestLine, dodo::network::protocol::http::HTTPResponse, and dodo::network::protocol::http::HTTPVersion.

The documentation for this class was generated from the following files:

src/include/network/protocol/http/httpfragment.hpp
src/lib/network/protocol/http/httpfragment.cpp
