Generic HTTPMessage, parent to HTTPRequest and HTTPResponse. More...

#include <httpmessage.hpp>

Inheritance diagram for dodo::network::protocol::http::HTTPMessage:

[legend]

Collaboration diagram for dodo::network::protocol::http::HTTPMessage:

[legend]

Public Member Functions
	HTTPMessage ()
	Default constructor. More...

void	addHeader (const std::string &key, const std::string &value)
	Add a header to the HTTPMessage. More...

void	clearHeaders ()
	Clear all headers. More...

const common::Bytes &	getBody () const
	Return the HTTTMessage body. More...

const std::map< std::string, std::string > &	getHeaders () const
	Return a reference to the headers map. More...

bool	getHeaderValue (const std::string &key, std::string &value) const
	Get a header value as a string into value. More...

bool	getHeaderValue (const std::string &key, unsigned long &value) const
	Get a header value as an unsigned long into value. More...

bool	hasHeader (const std::string &header) const
	Return true when this header key exists in this HTTPMessage's headers. More...

void	replaceHeader (const std::string &key, const std::string &value)
	Replace the value of a header. More...

virtual common::SystemError	send (BaseSocket *socket)=0
	Send this HTTPMessage to the socket. More...

void	setBody (const std::string &body)
	Set the body. More...

Public Member Functions inherited from dodo::network::protocol::http::HTTPFragment
virtual std::string	asString () const =0
	Convert the HTTPFragment in a HTTP protocol string. More...

virtual ParseResult	parse (VirtualReadBuffer &buffer)=0
	Read a complete HTTPFragment from a VirtualReadBuffer. More...

Static Public Attributes
static const char	charCR = char(13)
	CR character. More...

static const char	charHT = char(9)
	Horizontal tab character. More...

static const char	charLF = char(10)
	LF character. More...

static const char	charSP = char(32)
	Space character. More...

Protected Member Functions
ParseResult	eatCRLF (VirtualReadBuffer &data)
	Consume a CR LF sequence only when it is there. More...

virtual ParseResult	parseBody (VirtualReadBuffer &data)=0
	Parse a body and resturn it as a single string. More...

ParseResult	parseChunkedBody (VirtualReadBuffer &data)
	Parse a chunked body (transfer-encoding: chunked) and resturn it as a single string. More...

ParseResult	parseChunkHex (VirtualReadBuffer &data, unsigned long &value)
	Parse a hexadecimal chunk size (a hex value followed by CR LF). More...

ParseResult	parseCRLF (VirtualReadBuffer &data)
	Consume a CR LF sequence. More...

ParseResult	parseFieldValue (VirtualReadBuffer &data, std::string &value)
	Parse a header field value. More...

ParseResult	parseHeaders (VirtualReadBuffer &data)
	Parse a header section and update headers_. More...

ParseResult	parseToken (VirtualReadBuffer &buffer, std::string &token)
	Parse a token (such as a header field name). More...

Static Protected Member Functions
static common::SystemError	eatSpace (VirtualReadBuffer &data)
	Call buffer.next() as long as buffer.get() is whitespace ( charSP or charHT). More...

static bool	isCTL (char c)
	Check is the char is a CTL character. More...

static bool	isSeparator (char c)
	Return true if the char is a separator. More...

static bool	isSP (char c)
	Return true if the char is whitespace character (charSP or charHT) More...

static ParseResult	parseUInt (VirtualReadBuffer &data, unsigned int &value)
	Parse an unsigned integer. More...

Protected Attributes
common::Bytes	body_
	The message body (if any). More...

std::map< std::string, std::string >	headers_
	The message headers. More...

Additional Inherited Members
Public Types inherited from dodo::network::protocol::http::HTTPFragment
enum	ParseError : unsigned int { peOk = 0, peIncomplete, peSystemError, peExpectCRLF, peUnFinishedToken, peExpectingHeaderColon, peInvalidHeaderFieldValue, peInvalidHeaderListEnd, peInvalidMethod, peInvalidHTTPVersion, peInvalidRequestLine, peInvalidContentLength, peUnexpectedBody, peInvalidTransferEncoding, peInvalidChunkHex, peInvalidLastChunk, peExpectingUnsignedInt }
	Parse results returned by the parse functions. More...

Static Public Member Functions inherited from dodo::network::protocol::http::HTTPFragment
static std::string	getParseResultAsString (ParseError error)
	Return the string description of a ParseError. More...

Detailed Description

Generic HTTPMessage, parent to HTTPRequest and HTTPResponse.

See also: https://tools.ietf.org/html/rfc2616#page-15

Remarks: This class is not thread safe, but does not use any global variables.

Definition at line 40 of file httpmessage.hpp.

Constructor & Destructor Documentation

◆ HTTPMessage()

dodo::network::protocol::http::HTTPMessage::HTTPMessage ( )

inline

Default constructor.

Definition at line 67 of file httpmessage.hpp.

Member Function Documentation

◆ addHeader()

void dodo::network::protocol::http::HTTPMessage::addHeader	(	const std::string &	key,
		const std::string &	value
	)

Add a header to the HTTPMessage.

Note that multtiple headers may be specified with the same key but are supposed to be equavalent to a comma seperated list, so

addHeader( "key", "1" );
addHeader( "key", "2" );
addHeader( "key", "3" );

is equivalent to

addHeader( "key", "1,2,3" );

and this class transforms the former into the latter automatically.

Parameters

key	The header key.
value	The header value.

Definition at line 37 of file httpmessage.cpp.

References headers_.

Referenced by parseHeaders().

Here is the caller graph for this function:

◆ clearHeaders()

void dodo::network::protocol::http::HTTPMessage::clearHeaders ( )

inline

Clear all headers.

Definition at line 110 of file httpmessage.hpp.

References headers_.

◆ eatCRLF()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPMessage::eatCRLF ( VirtualReadBuffer & data )

protected

Consume a CR LF sequence only when it is there.

Unlike parseCRLF this function will not fail when the CRLF is not found.

Parameters

data	The VirtualReadBuffer to read from.

Returns: peOk or peExpectCRLF or peSystemError. The latter can only be returned when a CR is encountered without a LF after it.

Definition at line 46 of file httpmessage.cpp.

References charCR, charLF, dodo::common::SystemError::ecOK, dodo::network::VirtualReadBuffer::get(), dodo::network::VirtualReadBuffer::next(), dodo::network::protocol::http::HTTPFragment::ParseResult::ok(), dodo::network::protocol::http::HTTPFragment::peExpectCRLF, and dodo::network::protocol::http::HTTPFragment::ParseResult::setSystemError().

Here is the call graph for this function:

◆ eatSpace()

common::SystemError dodo::network::protocol::http::HTTPMessage::eatSpace ( VirtualReadBuffer & data )

staticprotected

Call buffer.next() as long as buffer.get() is whitespace ( charSP or charHT).

Parameters

data	The VirtualReadBuffer to read from.

Returns: A SystemError, like data tata presenting a CR but no LF after it.

Definition at line 56 of file httpmessage.cpp.

References charHT, charSP, dodo::common::SystemError::ecOK, dodo::network::VirtualReadBuffer::get(), and dodo::network::VirtualReadBuffer::next().

Referenced by dodo::network::protocol::http::HTTPRequest::HTTPRequestLine::parse(), dodo::network::protocol::http::HTTPResponse::HTTPResponseLine::parse(), and parseHeaders().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getBody()

const common::Bytes& dodo::network::protocol::http::HTTPMessage::getBody ( ) const

inline

Return the HTTTMessage body.

Returns: The HTTPMessage body.

Definition at line 133 of file httpmessage.hpp.

References body_.

◆ getHeaders()

const std::map<std::string,std::string>& dodo::network::protocol::http::HTTPMessage::getHeaders ( ) const

inline

Return a reference to the headers map.

Returns: A reference to headers_;

Definition at line 98 of file httpmessage.hpp.

References headers_.

◆ getHeaderValue() [1/2]

bool dodo::network::protocol::http::HTTPMessage::getHeaderValue	(	const std::string &	key,
		std::string &	value
	)		const

Get a header value as a string into value.

Parameters

key	The header key.
value	Receives the header value.

Returns: True if the key was found, false otherwise, in which case value is undefined.

Definition at line 74 of file httpmessage.cpp.

References headers_.

Referenced by dodo::network::protocol::http::HTTPResponse::hasBody(), dodo::network::protocol::http::HTTPRequest::parseBody(), and dodo::network::protocol::http::HTTPResponse::parseBody().

Here is the caller graph for this function:

◆ getHeaderValue() [2/2]

bool dodo::network::protocol::http::HTTPMessage::getHeaderValue	(	const std::string &	key,
		unsigned long &	value
	)		const

Get a header value as an unsigned long into value.

Parameters

key	The header key.
value	Receives the header value.

Returns: True if the key was found and the value an integer, false otherwise, in which case value is undefined.

Definition at line 64 of file httpmessage.cpp.

References headers_.

◆ hasHeader()

bool dodo::network::protocol::http::HTTPMessage::hasHeader ( const std::string & header ) const

inline

Return true when this header key exists in this HTTPMessage's headers.

Parameters

header The header key to check for (lowercase).

Returns: True then the header exists in this HTTPMessage's headers.

Definition at line 105 of file httpmessage.hpp.

References headers_.

◆ isCTL()

static bool dodo::network::protocol::http::HTTPMessage::isCTL ( char c )

inlinestaticprotected

Check is the char is a CTL character.

Parameters

c	The character to check.

Returns: true is c is a control character

See also: https://tools.ietf.org/html/rfc2616#page-15

Definition at line 164 of file httpmessage.hpp.

Referenced by parseToken().

Here is the caller graph for this function:

◆ isSeparator()

static bool dodo::network::protocol::http::HTTPMessage::isSeparator ( char c )

inlinestaticprotected

Return true if the char is a separator.

Parameters

c	The char to check.

Returns: True if c is a separator, false otherwise.

Todo:: the order of checks can be optimized on character frequency.

Definition at line 242 of file httpmessage.hpp.

References charHT, and charSP.

Referenced by parseToken().

Here is the caller graph for this function:

◆ isSP()

static bool dodo::network::protocol::http::HTTPMessage::isSP ( char c )

inlinestaticprotected

Return true if the char is whitespace character (charSP or charHT)

Parameters

c	The char to check.

Returns: True if c is whitespace, false otherwise.

Todo:: the order of checks can be optimized on character frequency.

Definition at line 255 of file httpmessage.hpp.

References charHT, and charSP.

Referenced by parseFieldValue().

Here is the caller graph for this function:

◆ parseBody()

virtual ParseResult dodo::network::protocol::http::HTTPMessage::parseBody ( VirtualReadBuffer & data )

protectedpure virtual

Parse a body and resturn it as a single string.

Note that the content-length header must be present and specify the correct body length.

Parameters

data	The VirtualReadBuffer to read from.

Returns: The ParseError.

Implemented in dodo::network::protocol::http::HTTPResponse, and dodo::network::protocol::http::HTTPRequest.

◆ parseChunkedBody()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPMessage::parseChunkedBody ( VirtualReadBuffer & data )

protected

Parse a chunked body (transfer-encoding: chunked) and resturn it as a single string.

Parameters

data	The VirtualReadBuffer to read from.

Returns: The ParseError.

Definition at line 224 of file httpmessage.cpp.

References dodo::common::Bytes::append(), body_, dodo::common::SystemError::ecOK, dodo::network::protocol::http::HTTPFragment::ParseResult::eof(), dodo::network::VirtualReadBuffer::get(), dodo::network::VirtualReadBuffer::next(), dodo::network::protocol::http::HTTPFragment::ParseResult::ok(), parseChunkHex(), parseCRLF(), dodo::network::protocol::http::HTTPFragment::peInvalidLastChunk, dodo::network::protocol::http::HTTPFragment::peOk, and dodo::network::protocol::http::HTTPFragment::ParseResult::setSystemError().

Referenced by dodo::network::protocol::http::HTTPRequest::parseBody(), and dodo::network::protocol::http::HTTPResponse::parseBody().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parseChunkHex()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPMessage::parseChunkHex	(	VirtualReadBuffer &	data,
		unsigned long &	value
	)

protected

Parse a hexadecimal chunk size (a hex value followed by CR LF).

Parameters

data	The VirtualReadBuffer to read from.
value	The value receiving the chunk size.

Returns: The ParseResult, either peOk, peExpectCRLF or peInvalidChunkHex.

Definition at line 125 of file httpmessage.cpp.

References dodo::common::SystemError::ecOK, dodo::network::VirtualReadBuffer::get(), dodo::network::VirtualReadBuffer::next(), dodo::network::protocol::http::HTTPFragment::ParseResult::ok(), parseCRLF(), dodo::network::protocol::http::HTTPFragment::peInvalidChunkHex, and dodo::network::protocol::http::HTTPFragment::ParseResult::setSystemError().

Referenced by parseChunkedBody().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parseCRLF()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPMessage::parseCRLF ( VirtualReadBuffer & data )

protected

Consume a CR LF sequence.

Parameters

data	The VirtualReadBuffer to read from.

Returns: The ParseResult

Definition at line 115 of file httpmessage.cpp.

References charCR, charLF, dodo::common::SystemError::ecOK, dodo::network::VirtualReadBuffer::get(), dodo::network::VirtualReadBuffer::next(), dodo::network::protocol::http::HTTPFragment::ParseResult::ok(), dodo::network::protocol::http::HTTPFragment::peExpectCRLF, and dodo::network::protocol::http::HTTPFragment::ParseResult::setSystemError().

Referenced by parseChunkedBody(), and parseChunkHex().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parseFieldValue()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPMessage::parseFieldValue	(	VirtualReadBuffer &	data,
		std::string &	value
	)

protected

Parse a header field value.

Parameters

data	The VirtualReadBuffer to read from.
value	The value receiving the field-value.

Returns: The ParseResult.

Definition at line 141 of file httpmessage.cpp.

References charCR, charLF, charSP, dodo::common::SystemError::ecOK, dodo::network::VirtualReadBuffer::get(), isSP(), dodo::network::VirtualReadBuffer::next(), dodo::network::protocol::http::HTTPFragment::ParseResult::ok(), dodo::network::protocol::http::HTTPFragment::peExpectCRLF, dodo::network::protocol::http::HTTPFragment::peInvalidHeaderFieldValue, and dodo::network::protocol::http::HTTPFragment::ParseResult::setSystemError().

Referenced by parseHeaders().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parseHeaders()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPMessage::parseHeaders ( VirtualReadBuffer & data )

protected

Parse a header section and update headers_.

Parameters

data	The VirtualReadBuffer to read from.

Returns: The ParseResult.

Definition at line 83 of file httpmessage.cpp.

References addHeader(), charCR, charLF, eatSpace(), dodo::common::SystemError::ecOK, dodo::network::protocol::http::HTTPFragment::ParseResult::eof(), dodo::network::VirtualReadBuffer::get(), dodo::network::VirtualReadBuffer::next(), dodo::network::protocol::http::HTTPFragment::ParseResult::ok(), parseFieldValue(), parseToken(), dodo::network::protocol::http::HTTPFragment::peExpectingHeaderColon, dodo::network::protocol::http::HTTPFragment::peInvalidHeaderListEnd, and dodo::network::protocol::http::HTTPFragment::ParseResult::setSystemError().

Referenced by dodo::network::protocol::http::HTTPRequest::parse(), and dodo::network::protocol::http::HTTPResponse::parse().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parseToken()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPMessage::parseToken	(	VirtualReadBuffer &	buffer,
		std::string &	token
	)

protected

Parse a token (such as a header field name).

Parameters

buffer	The HTTP data source.
token	The value receiving the token.

Returns: The ParseResult.

Definition at line 196 of file httpmessage.cpp.

References dodo::common::SystemError::ecOK, dodo::network::VirtualReadBuffer::get(), isCTL(), isSeparator(), dodo::network::VirtualReadBuffer::next(), dodo::network::protocol::http::HTTPFragment::ParseResult::ok(), dodo::network::protocol::http::HTTPFragment::peOk, dodo::network::protocol::http::HTTPFragment::peUnFinishedToken, and dodo::network::protocol::http::HTTPFragment::ParseResult::setSystemError().

Referenced by parseHeaders().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parseUInt()

HTTPMessage::ParseResult dodo::network::protocol::http::HTTPMessage::parseUInt	(	VirtualReadBuffer &	data,
		unsigned int &	value
	)

staticprotected

Parse an unsigned integer.

Parameters

data	The VirtualReadBuffer to read from.
value	The value receiving the unsigned int.

Returns: The ParseResult.

Definition at line 211 of file httpmessage.cpp.

References dodo::common::SystemError::ecOK, dodo::network::VirtualReadBuffer::get(), dodo::network::VirtualReadBuffer::next(), dodo::network::protocol::http::HTTPFragment::ParseResult::ok(), dodo::network::protocol::http::HTTPFragment::peExpectingUnsignedInt, and dodo::network::protocol::http::HTTPFragment::ParseResult::setSystemError().

Referenced by dodo::network::protocol::http::HTTPResponse::HTTPResponseLine::parse().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ replaceHeader()

void dodo::network::protocol::http::HTTPMessage::replaceHeader	(	const std::string &	key,
		const std::string &	value
	)

Replace the value of a header.

Parameters

key	the key to replace.
value	the value to set.

Definition at line 244 of file httpmessage.cpp.

References headers_.

Referenced by setBody().

Here is the caller graph for this function:

◆ send()

virtual common::SystemError dodo::network::protocol::http::HTTPMessage::send ( BaseSocket * socket )

pure virtual

Send this HTTPMessage to the socket.

Parameters

socket The socket to write to.

Returns: The commonSystemError that might accour.

Implemented in dodo::network::protocol::http::HTTPResponse, and dodo::network::protocol::http::HTTPRequest.

◆ setBody()

void dodo::network::protocol::http::HTTPMessage::setBody ( const std::string & body )

Set the body.

Parameters

body	The body to set.

Definition at line 248 of file httpmessage.cpp.

References body_, dodo::common::Bytes::getSize(), and replaceHeader().

Here is the call graph for this function:

Field Documentation

◆ body_

common::Bytes dodo::network::protocol::http::HTTPMessage::body_

protected

The message body (if any).

Definition at line 267 of file httpmessage.hpp.

Referenced by dodo::network::protocol::http::HTTPRequest::asString(), dodo::network::protocol::http::HTTPResponse::asString(), getBody(), dodo::network::protocol::http::HTTPRequest::parseBody(), dodo::network::protocol::http::HTTPResponse::parseBody(), parseChunkedBody(), dodo::network::protocol::http::HTTPRequest::send(), dodo::network::protocol::http::HTTPResponse::send(), and setBody().

◆ charCR

const char dodo::network::protocol::http::HTTPMessage::charCR = char(13)

static

CR character.

Definition at line 47 of file httpmessage.hpp.

◆ charHT

const char dodo::network::protocol::http::HTTPMessage::charHT = char(9)

static

Horizontal tab character.

Definition at line 62 of file httpmessage.hpp.

Referenced by eatSpace(), isSeparator(), and isSP().

◆ charLF

const char dodo::network::protocol::http::HTTPMessage::charLF = char(10)

static

LF character.

Definition at line 52 of file httpmessage.hpp.

◆ charSP

const char dodo::network::protocol::http::HTTPMessage::charSP = char(32)

static

Space character.

Definition at line 57 of file httpmessage.hpp.

Referenced by dodo::network::protocol::http::HTTPRequest::HTTPRequestLine::asString(), dodo::network::protocol::http::HTTPResponse::HTTPResponseLine::asString(), eatSpace(), isSeparator(), isSP(), and parseFieldValue().

◆ headers_

std::map<std::string,std::string> dodo::network::protocol::http::HTTPMessage::headers_

protected

The message headers.

Definition at line 262 of file httpmessage.hpp.

Referenced by addHeader(), dodo::network::protocol::http::HTTPRequest::asString(), dodo::network::protocol::http::HTTPResponse::asString(), clearHeaders(), getHeaders(), getHeaderValue(), hasHeader(), replaceHeader(), dodo::network::protocol::http::HTTPRequest::send(), and dodo::network::protocol::http::HTTPResponse::send().

The documentation for this class was generated from the following files:

src/include/network/protocol/http/httpmessage.hpp
src/lib/network/protocol/http/httpmessage.cpp

Public Member Functions

Static Public Attributes

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ HTTPMessage()

Member Function Documentation

◆ addHeader()

◆ clearHeaders()

◆ eatCRLF()

◆ eatSpace()

◆ getBody()

◆ getHeaders()

◆ getHeaderValue() [1/2]

◆ getHeaderValue() [2/2]

◆ hasHeader()

◆ isCTL()

◆ isSeparator()

◆ isSP()

◆ parseBody()

◆ parseChunkedBody()

◆ parseChunkHex()

◆ parseCRLF()

◆ parseFieldValue()

◆ parseHeaders()

◆ parseToken()

◆ parseUInt()

◆ replaceHeader()

◆ send()

◆ setBody()

Field Documentation

◆ body_

◆ charCR

◆ charHT

◆ charLF

◆ charSP

◆ headers_
