A Linux socket. More...

#include <socket.hpp>

Inheritance diagram for dodo::network::Socket:

Collaboration diagram for dodo::network::Socket:

Public Member Functions
	Socket ()
	Default constructor creates an invalid socket. More...

	Socket (bool blocking)
	Construct with default SocketParams. More...

	Socket (bool blocking, SocketParams params)
	Construct from SocketParams. More...

	Socket (int socket)
	Construct from a socket descriptor. More...

virtual	~Socket ()
	Destructs this Socket, but does not call close(). More...

virtual Socket *	accept ()
	Accepts a connection request and return a pointer to a new Socket for the new connection, the caller will own the new Socket object. More...

virtual common::SystemError	receive (void *buf, ssize_t request, ssize_t &received)
	Receive bytes. More...

virtual common::SystemError	send (const void *buf, ssize_t len, bool more=false)
	Send len bytes as a bytestream. More...

virtual common::SystemError	sendTo (const Address &address, const void *buf, ssize_t len)
	Send raw packets to the given Address. More...

Public Member Functions inherited from dodo::network::BaseSocket
	BaseSocket ()
	Default constructor creates an invalid socket. More...

	BaseSocket (bool blocking, SocketParams params)
	Construct from SocketParams. More...

	BaseSocket (int socket)
	Construct from a socket descriptor. More...

virtual	~BaseSocket ()
	Destructs this Socket, but does not call close(). More...

common::SystemError	bind (const Address &address)
	Bind the socket to the Address. More...

virtual void	close ()
	Closes the socket, causing the connection, if it exists, to be terminated. More...

virtual common::SystemError	connect (const Address &address)
	Connect to the address. More...

virtual std::string	debugDetail () const
	Return debug object state as a string. More...

Address	getAddress () const
	Get the local address for this socket. More...

SocketParams::AddressFamily	getAddressFamily () const
	Get the SocketParams::AddressFamily of the socket. More...

virtual bool	getBlocking () const
	Rerurn true if the socket is operating in blocking mode. More...

int	getFD () const
	Return the socket file descriptor. More...

Address	getPeerAddress () const
	Get the peer (remote) address for this socket. More...

SocketParams::ProtocolNumber	getProtocolNumber () const
	Get the SocketParams::ProtocolNumber of the socket. More...

virtual socklen_t	getReceiveBufSize () const
	Get the maximum buffer length for receive. More...

socklen_t	getSendBufSize () const
	Get the maximum buffer length for send. More...

SocketParams	getSocketParams () const
	Return the SocketParams. More...

SocketParams::SocketType	getSocketType () const
	Get the SocketParams::SocketType of the socket. More...

int	getTTL () const
	Get the Socket TTL (time to live) or the max number of packet hops. More...

bool	isValid () const
	Return true when the socket descriptor is a valid, hence 'possible' descriptor. More...

common::SystemError	listen (const Address &address, int backlog)
	Sets up a listening socket on Address. More...

bool	operator< (const BaseSocket &socket) const
	Add ordering. More...

BaseSocket &	operator= (const BaseSocket &socket)
	Assign from Socket. More...

BaseSocket &	operator= (int socket)
	Assign from existing socket descriptor (int). More...

bool	operator== (const BaseSocket &socket) const
	Add identity. More...

common::SystemError	receiveInt16 (int16_t &value)
	receive an int16_t More...

common::SystemError	receiveInt32 (int32_t &value)
	receive an int32_t More...

common::SystemError	receiveInt64 (int64_t &value)
	receive an int64_t More...

common::SystemError	receiveInt8 (int8_t &value)
	receive an int8_t More...

common::SystemError	receiveLine (std::string &s)
	receive a stream of characters until a ' ' is read (consumed from the socket read buffer but not added to s). More...

common::SystemError	receiveString (std::string &s)
	Receive a std::string as sent by sendString( const std::string& ). More...

common::SystemError	receiveUInt16 (uint16_t &value)
	receive an uint16_t More...

common::SystemError	receiveUInt32 (uint32_t &value)
	receive an uint32_t More...

common::SystemError	receiveUInt64 (uint64_t &value)
	receive an uint64_t More...

common::SystemError	receiveUInt8 (uint8_t &value)
	receive an uint8_t More...

common::SystemError	sendInt16 (int16_t value, bool more=false)
	Send an int16_t. More...

common::SystemError	sendInt32 (int32_t value, bool more=false)
	Send an int32_t. More...

common::SystemError	sendInt64 (int64_t value, bool more=false)
	Send an int64_t. More...

common::SystemError	sendInt8 (int8_t value, bool more=false)
	Send an int8_t. More...

common::SystemError	sendLine (const std::string &s, bool more)
	Sends the std::string terminated by a ' '. More...

common::SystemError	sendString (const std::string &s, bool more=false)
	Sends the std::string as understood by receiveString(). More...

common::SystemError	sendUInt16 (uint16_t value, bool more=false)
	Send an uint16_t. More...

common::SystemError	sendUInt32 (uint32_t value, bool more=false)
	Send an uint32_t. More...

common::SystemError	sendUInt64 (uint64_t value, bool more=false)
	Send an sendUInt64. More...

common::SystemError	sendUInt8 (uint8_t value, bool more=false)
	Send an uint8_t. More...

void	setBlocking (bool blocking)
	Set the Socket blocking mode. More...

void	setReceiveBufSize (socklen_t size)
	Set the size of the receive buffer. More...

void	setReceiveTimeout (double sec)
	Set the receive timeout - a receive will fail if there is no data received before the timeout expires. More...

void	setReUseAddress ()
	Enable the socket to re-use an address when listen/bind is called. More...

void	setReUsePort ()
	Make the socket re-use a port when listen is called. More...

void	setSendBufSize (socklen_t size)
	Set the size of the send buffer. More...

void	setSendTimeout (double sec)
	Set the send timeout - a send will fail if there is no data send before the timeout expires. More...

void	setTCPKeepAlive (bool enable)
	Enable or disable TCP keep-alive on the socket. More...

void	setTCPNoDelay (bool set)
	Set TCP_NODELAY. More...

void	setTTL (int ttl)
	Set the Socket TTL (Time to Live). More...

Public Member Functions inherited from dodo::common::DebugObject
	DebugObject ()
	Default constructor does nothing. More...

virtual	~DebugObject ()
	Destructor does nothing. More...

std::string	debugString () const
	Return the object dump to string. More...

Static Public Attributes
static Socket	SocketInvalid = Socket()
	An invalid SocketInvalid for comparison convenience - initialized to a Socket with socket fd=-1. More...

Additional Inherited Members
Protected Member Functions inherited from dodo::common::DebugObject
std::string	debugHeader () const
	Generates a debug header (address of this object and a demangled class name. More...

Protected Attributes inherited from dodo::network::BaseSocket
int	socket_
	The socket file decsriptor. More...

Detailed Description

A Linux socket.

Socket objects refer to, but do not own a particular socket descriptor. The programmer controls closing the socket by calling close(), the Socket destructor does not do this implicitly, as two Socket objects may refer to the same socket descriptor.

The Socket operates either in blocking or non-blocking mode. In blocking mode, calls to listen() or receive() will block until data is received. Moreover, in blocking mode, there is no limit to the amount of data that can be sent or received in one go. In non-blocking mode, the send and receive sizes per call must fit in Socket::getSendBufSize() or Socket::getReceiveBufSize().

Definition at line 50 of file socket.hpp.

Constructor & Destructor Documentation

◆ Socket() [1/4]

dodo::network::Socket::Socket ( )

inline

Default constructor creates an invalid socket.

Definition at line 57 of file socket.hpp.

Referenced by accept().

Here is the caller graph for this function:

◆ Socket() [2/4]

dodo::network::Socket::Socket ( int socket )

inline

Construct from a socket descriptor.

Parameters

socket The socket file descriptor.

Definition at line 63 of file socket.hpp.

◆ Socket() [3/4]

dodo::network::Socket::Socket	(	bool	blocking,
		SocketParams	params
	)

inline

Construct from SocketParams.

Parameters

blocking	If true, create the socket in blocking mode.
params	The SocketParams to use.

Definition at line 70 of file socket.hpp.

◆ Socket() [4/4]

dodo::network::Socket::Socket ( bool blocking )

inline

Construct with default SocketParams.

Parameters

blocking If true, create the socket in blocking mode.

Definition at line 76 of file socket.hpp.

◆ ~Socket()

virtual dodo::network::Socket::~Socket ( )

inlinevirtual

Destructs this Socket, but does not call close().

Definition at line 81 of file socket.hpp.

Member Function Documentation

◆ accept()

Socket * dodo::network::Socket::accept ( )

virtual

Accepts a connection request and return a pointer to a new Socket for the new connection, the caller will own the new Socket object.

Returns: The accepted socket.

Implements dodo::network::BaseSocket.

Definition at line 98 of file socket.cpp.

References Socket(), dodo::network::BaseSocket::socket_, SocketInvalid, and throw_SystemExceptionObject.

Here is the call graph for this function:

◆ receive()

common::SystemError dodo::network::Socket::receive	(	void *	buf,
		ssize_t	request,
		ssize_t &	received
	)

virtual

Receive bytes.

Parameters

buf	The buffer to receive the data into.
request	The number of bytes to receive (request <= sizeof(buf) ).
received	The number of bytes actuially received

Returns

The error code:

SystemError::ecOK
SystemError::ecEAGAIN
SystemError::ecENOTCONN
SystemError::ecECONNREFUSED On other errors returned by the internal call to recv, an exception is thrown.

Implements dodo::network::BaseSocket.

Definition at line 81 of file socket.cpp.

References dodo::common::SystemError::ecEAGAIN, dodo::common::SystemError::ecECONNREFUSED, dodo::common::SystemError::ecENOTCONN, dodo::common::SystemError::ecOK, dodo::network::BaseSocket::socket_, and throw_SystemExceptionObject.

◆ send()

common::SystemError dodo::network::Socket::send	(	const void *	buf,
		ssize_t	len,
		bool	more = `false`
	)

virtual

Send len bytes as a bytestream.

connect must have been called first.

Parameters

buf	The bytes to send.
len	The number of bytes to send from buf.
more	If true, do no forec a network send right away, but wait until send buffer full or a subsequent call with more set to false.

Returns

SystemError::ecOK or

SystemError::ecEAGAIN: For non-blocking sockets, neither failure nor succces, try again.
SystemError::ecECONNRESET : The peer has disconnected during the send.

See also: sendTo()

Implements dodo::network::BaseSocket.

Definition at line 36 of file socket.cpp.

References dodo::common::SystemError::ecEAGAIN, dodo::common::SystemError::ecECONNRESET, dodo::common::SystemError::ecOK, dodo::network::BaseSocket::socket_, and throw_SystemExceptionObject.

◆ sendTo()

common::SystemError dodo::network::Socket::sendTo	(	const Address &	address,
		const void *	buf,
		ssize_t	len
	)

virtual

Send raw packets to the given Address.

Parameters

address	The destination Address
buf	The bytes to send
len	The number of bytes to send.

Returns: The SystemError.

Definition at line 59 of file socket.cpp.

References dodo::network::Address::addr_, dodo::common::SystemError::ecEAGAIN, dodo::common::SystemError::ecECONNRESET, dodo::common::SystemError::ecOK, dodo::network::BaseSocket::socket_, and throw_SystemExceptionObject.

Field Documentation

◆ SocketInvalid

Socket dodo::network::Socket::SocketInvalid = Socket()

static

An invalid SocketInvalid for comparison convenience - initialized to a Socket with socket fd=-1.

Definition at line 129 of file socket.hpp.

Referenced by accept().

The documentation for this class was generated from the following files:

src/include/network/socket.hpp
src/lib/network/socket.cpp
