dodo::network::X509CertificateSigningRequest Class Reference

X509 Certificate signing request (CSR) interface. More...

#include <x509cert.hpp>

Inheritance diagram for dodo::network::X509CertificateSigningRequest:

Collaboration diagram for dodo::network::X509CertificateSigningRequest:

Static Public Member Functions
static void	free (X509_REQ *cert)
	Free / clean an X509 object. More...
static std::string	getFingerPrint (const X509_REQ *cert, const std::string hashname="shake256")
	Get the certificate fingerprint (a hash on the public key modulus) in string format, multiple hexadecimal bytes values separated by a colon. More...
static X509Common::Identity	getSubject (const X509_REQ *cert)
	Get the CSR subject identity. More...
static X509_REQ *	loadPEM (const std::string file)
	Load a certificate signing request (CSR) from a PEM file. More...
Static Public Member Functions inherited from dodo::network::X509Common
static X509Type	detectX509Type (const std::string file, std::string &tag)
	Detects a X509 document type from a PEM file. More...
static std::string	SANTypeAsString (const SANType &san_type)
	Convert the SANType name to a string. More...

Private Member Functions
	X509CertificateSigningRequest ()=delete
	Never construct, interface class. More...
	~X509CertificateSigningRequest ()=delete
	Never destruct, interface class. More...

Additional Inherited Members
Public Types inherited from dodo::network::X509Common
enum	SANType { SANType::stDNS = GEN_DNS, SANType::stURI = GEN_URI, SANType::stEMAIL = GEN_EMAIL, SANType::stIP = GEN_IPADD }
	The SubjectAltName type. More...
enum	X509Type {   X509Type::Unknown, X509Type::PrivateKey, X509Type::PublicKey, X509Type::CertificateSigningRequest,   X509Type::Certificate }
	Enumeration of X509 document types. More...
Static Protected Member Functions inherited from dodo::network::X509Common
static Identity	parseIdentity (const std::string src)
	Parse a subject or issuer string into an Identity. More...

Detailed Description

X509 Certificate signing request (CSR) interface.

Note that this is an interface class, it does not manage ownership of X509_REQ structures.

See Secure sockets for details on the role of this class.

Definition at line 205 of file x509cert.hpp.

Constructor & Destructor Documentation

X509CertificateSigningRequest()

dodo::network::X509CertificateSigningRequest::X509CertificateSigningRequest ( )

privatedelete

Never construct, interface class.

~X509CertificateSigningRequest()

dodo::network::X509CertificateSigningRequest::~X509CertificateSigningRequest ( )

privatedelete

Never destruct, interface class.

Member Function Documentation

free()

static void dodo::network::X509CertificateSigningRequest::free ( X509_REQ *  cert )

inlinestatic

Free / clean an X509 object.

Parameters

cert	The X509_REQ object to free.

Definition at line 226 of file x509cert.hpp.

getFingerPrint()

std::string dodo::network::X509CertificateSigningRequest::getFingerPrint ( const X509_REQ *  cert, const std::string  hashname = "shake256"  )

static

Get the certificate fingerprint (a hash on the public key modulus) in string format, multiple hexadecimal bytes values separated by a colon.

openssl list -digest-algorithms shows a full list of hash (digest) names. Stick to newer hash algorithms from the SHA-3 family.

Exceptions

common::Exception

if the digest name is invalid.

See also

https://en.wikipedia.org/wiki/Secure_Hash_Algorithms

Parameters

cert	A pointer to the X509 certificate.
hashname	The name of the hash algorithm to use. Defaults to 'shake256'. Names are case-insensitive.

Returns

A string representation of the fingerprint.

Definition at line 121 of file x509cert.cpp.

References dodo::common::getSSLErrors(), and throw_Exception.

Here is the call graph for this function:

getSubject()

X509Common::Identity dodo::network::X509CertificateSigningRequest::getSubject ( const X509_REQ *  cert )

static

Get the CSR subject identity.

Parameters

cert	The source CSR / X509_REQ.

Returns

the CSR subject identity.

Definition at line 112 of file x509cert.cpp.

References dodo::common::bio2String(), and dodo::network::X509Common::parseIdentity().

Here is the call graph for this function:

loadPEM()

X509_REQ * dodo::network::X509CertificateSigningRequest::loadPEM ( const std::string  file )

static

Load a certificate signing request (CSR) from a PEM file.

The X509_REQ object pointed to gets owned by the caller and must be freed with free( X509_REQ* cert ). Note that the call will fail if the file is not a CSR, even if it is a valid PEM file - such as a certificate or a private key in PEM format.

Parameters

file	The filename to load from.

Exceptions

common::Exception	when the openSSL BIO fails to create.
common::Exception	when the file cannot be read.
common::Exception	when the file is not a valid PEM file.

Returns

Pointer to your X509_REQ.

Definition at line 92 of file x509cert.cpp.

References dodo::common::getSSLErrors(), and throw_Exception.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/include/network/x509cert.hpp
• src/lib/network/x509cert.cpp
