X509 public key certificate (PKC) interface. More...

#include <x509cert.hpp>

Inheritance diagram for dodo::network::X509Certificate:

Collaboration diagram for dodo::network::X509Certificate:

Static Public Member Functions
static void	free (X509 *cert)
	Free / clean an X509 object. More...

static std::string	getFingerPrint (const X509 *cert, const std::string hashname="shake256")
	Get the certificate fingerprint (a hash on the public key modulus) in string format, multiple hexadecimal bytes values separated by a colon. More...

static X509Common::Identity	getIssuer (const X509 *cert)
	Get the certificate issuer. More...

static std::string	getSerial (const X509 *cert)
	Get the certificate serial number as concatenated hex bytes. More...

static X509Common::Identity	getSubject (const X509 *cert)
	Get the certificate subject identity. More...

static std::list< X509Common::SAN >	getSubjectAltNames (const X509 *cert)
	Get the SAN (subject alternate name) list for the certificate, which may be empty. More...

static X509 *	loadPEM (const std::string file)
	Load a public key certificate (aka 'certificate') from a PEM file. More...

static bool	verifySAN (const X509 *cert, const SAN &san, bool wildcards=false)
	Verify a peer name against this certificate's CN and SubjectAltnames. More...

Static Public Member Functions inherited from dodo::network::X509Common
static X509Type	detectX509Type (const std::string file, std::string &tag)
	Detects a X509 document type from a PEM file. More...

static std::string	SANTypeAsString (const SANType &san_type)
	Convert the SANType name to a string. More...

Private Member Functions
	X509Certificate ()=delete
	Never construct, interface class. More...

	~X509Certificate ()=delete
	Never destruct, interface class. More...

Static Private Member Functions
static bool	verifyIP (const std::string &peer, const std::string &san)
	Verify a peer IP matches a SAN of type stIP. More...

static bool	verifyName (const std::string &peer, const std::string &san, bool wildcards=false)
	Verify a peer name matches a SAN. More...

Additional Inherited Members
Public Types inherited from dodo::network::X509Common
enum	SANType { SANType::stDNS = GEN_DNS, SANType::stURI = GEN_URI, SANType::stEMAIL = GEN_EMAIL, SANType::stIP = GEN_IPADD }
	The SubjectAltName type. More...

enum	X509Type { X509Type::Unknown, X509Type::PrivateKey, X509Type::PublicKey, X509Type::CertificateSigningRequest, X509Type::Certificate }
	Enumeration of X509 document types. More...

Static Protected Member Functions inherited from dodo::network::X509Common
static Identity	parseIdentity (const std::string src)
	Parse a subject or issuer string into an Identity. More...

Detailed Description

X509 public key certificate (PKC) interface.

Note that this is an interface class, it does not manage ownership of X509 structures.

See Secure sockets for details on the role of this class.

Definition at line 265 of file x509cert.hpp.

Constructor & Destructor Documentation

◆ X509Certificate()

dodo::network::X509Certificate::X509Certificate ( )

privatedelete

Never construct, interface class.

◆ ~X509Certificate()

dodo::network::X509Certificate::~X509Certificate ( )

privatedelete

Never destruct, interface class.

Member Function Documentation

◆ free()

static void dodo::network::X509Certificate::free ( X509 * cert )

inlinestatic

Free / clean an X509 object.

Parameters

cert	A pointer to the X509 certificate.

Definition at line 285 of file x509cert.hpp.

Referenced by getSerial().

Here is the caller graph for this function:

◆ getFingerPrint()

std::string dodo::network::X509Certificate::getFingerPrint	(	const X509 *	cert,
		const std::string	hashname = `"shake256"`
	)

static

Get the certificate fingerprint (a hash on the public key modulus) in string format, multiple hexadecimal bytes values separated by a colon.

openssl list -digest-algorithms shows a full list of hash (digest) names. Stick to newer hash algorithms from the SHA-3 family.

Exceptions

common::Exception if the digest name is invalid.

See also: https://en.wikipedia.org/wiki/Secure_Hash_Algorithms

Parameters

cert	A pointer to the X509 certificate.
hashname	The name of the hash algorithm to use. Defaults to 'shake256'. Names are case-insensitive.

Returns: A string representation of the fingerprint.

Definition at line 230 of file x509cert.cpp.

References dodo::common::getSSLErrors(), and throw_Exception.

Here is the call graph for this function:

◆ getIssuer()

X509Common::Identity dodo::network::X509Certificate::getIssuer ( const X509 * cert )

static

Get the certificate issuer.

Parameters

cert	A pointer to the X509 certificate.

Returns: the issuer string.

Definition at line 163 of file x509cert.cpp.

References dodo::common::bio2String(), and dodo::network::X509Common::parseIdentity().

Here is the call graph for this function:

◆ getSerial()

std::string dodo::network::X509Certificate::getSerial ( const X509 * cert )

static

Get the certificate serial number as concatenated hex bytes.

Note that the serial number is only supposed to be unique among certificates signed by a single CA. To truly identify certificates, use getFingerPrint().

Parameters

cert	The source PKC / X509.

Returns: the serial string.

Definition at line 172 of file x509cert.cpp.

References free().

Here is the call graph for this function:

◆ getSubject()

X509Common::Identity dodo::network::X509Certificate::getSubject ( const X509 * cert )

static

Get the certificate subject identity.

Parameters

cert	A pointer to the X509 certificate.

Returns: the subject identity.

Definition at line 182 of file x509cert.cpp.

References dodo::common::bio2String(), and dodo::network::X509Common::parseIdentity().

Referenced by verifySAN().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getSubjectAltNames()

std::list< X509Certificate::SAN > dodo::network::X509Certificate::getSubjectAltNames ( const X509 * cert )

static

Get the SAN (subject alternate name) list for the certificate, which may be empty.

Parameters

cert	A pointer to the X509 certificate.

Returns: A list of SAN.

Definition at line 192 of file x509cert.cpp.

Referenced by verifySAN().

Here is the caller graph for this function:

◆ loadPEM()

X509 * dodo::network::X509Certificate::loadPEM ( const std::string file )

static

Load a public key certificate (aka 'certificate') from a PEM file.

The X509 object pointed to gets owned by the caller and must be freed when done with free( X509* cert ). Note that the call will fail if the file is not a public key certificate, even though it is a valid PEM file. Also note that the call will return ony the first certificate if the PEM file contains multiple certificates.

Parameters

file	The PEM file to load from.

Exceptions

common::Exception	when the openSSL BIO fails to create.
common::Exception	when the file cannot be read.
common::Exception	when the file is not a valid PEM file.

Returns: Pointer to the X509 document.

Definition at line 143 of file x509cert.cpp.

References dodo::common::getSSLErrors(), and throw_Exception.

Here is the call graph for this function:

◆ verifyIP()

bool dodo::network::X509Certificate::verifyIP	(	const std::string &	peer,
		const std::string &	san
	)

staticprivate

Verify a peer IP matches a SAN of type stIP.

The strings are converted to IP addresses, both must be valid IP addresses and they must be equal ( Address::operator==( const Address &) ).

Parameters

peer	The ipv4 or ipv6 of the peer (as a string).
san	The ipv4 or ipv6 SubjectAltname of the peer (as a string).

Returns: true when the IP matches.

Definition at line 269 of file x509cert.cpp.

References dodo::network::Address::isValid().

Here is the call graph for this function:

◆ verifyName()

bool dodo::network::X509Certificate::verifyName	(	const std::string &	peer,
		const std::string &	san,
		bool	wildcards = `false`
	)

staticprivate

Verify a peer name matches a SAN.

Parameters

peer	The name of the peer.
san	The SubjectAltname of the peer.
wildcards	If true, allow wildcards.

Returns: true when the name matches.

Definition at line 248 of file x509cert.cpp.

◆ verifySAN()

bool dodo::network::X509Certificate::verifySAN	(	const X509 *	cert,
		const SAN &	san,
		bool	wildcards = `false`
	)

static

Verify a peer name against this certificate's CN and SubjectAltnames.

The name is always matched against the CN, regardless of the X509Common::SANType. The name is matched against SubjectAltNames that match the X509Common::SANType.

Parameters

cert	A pointer to the X509 certificate.
san	The SAN structure to compare against.
wildcards	If true, allow wildcards.

Returns: true if the name matches.

Definition at line 278 of file x509cert.cpp.

References dodo::network::X509Common::Identity::commonName, getSubject(), getSubjectAltNames(), dodo::network::X509Common::SAN::san_type, dodo::network::X509Common::stDNS, dodo::network::X509Common::stEMAIL, dodo::network::X509Common::stIP, and dodo::network::X509Common::stURI.

Referenced by dodo::network::TLSSocket::connect().

Here is the call graph for this function:

Here is the caller graph for this function:

The documentation for this class was generated from the following files:

src/include/network/x509cert.hpp
src/lib/network/x509cert.cpp
