Used in conjunction with TCPListener to implement high speed, multithreaded TCP services. More...

#include <tcpserver.hpp>

Inheritance diagram for dodo::network::TCPServer:

Collaboration diagram for dodo::network::TCPServer:

[legend]

Public Types
enum	ServerState { ssWait = 0, ssAwoken = 1, ssHandshake = 2, ssHandshakeDone = 3, ssReadSocket = 4, ssReadSocketDone = 5, ssShutdown = 6, ssShutdownDone = 7, ssReleaseWork = 8, ssReleaseWorkDone = 9 }
	The possible states of a TCPServer. More...

Public Member Functions
	TCPServer (TCPListener &listener)
	Construct a TCPServer for the TCPListener. More...

virtual TCPServer *	addServer ()=0
	Spawn a new TCPServer. More...

double	getIdleSeconds ()
	Get the number of secodns the TCPServer has been idle. More...

bool	getRequestStop () const
	Return true if the TCPServer was requested to stop. More...

ServerState	getState () const
	Return the current ServerState. More...

virtual bool	handShake (network::BaseSocket *socket, ssize_t &received, ssize_t &sent)=0
	Override to perform a protocol handshake. More...

bool	hasStopped () const
	Return true if the TCPServer has stopped working. More...

bool	isBusy () const
	Return true if the TCPServer is busy. More...

virtual TCPConnectionData *	newConnectionData () const
	Return a new TCPConnectionData pointer or override to return a descendant of TCPConnectionData. More...

virtual common::SystemError	readSocket (TCPListener::SocketWork &work, ssize_t &sent)=0
	Override to perform a request-response cycle. More...

void	requestStop ()
	Set the request_stop_ flag, this call returns immediately, stopping will follow. More...

virtual void	run ()
	Run the TCPServer thread. More...

virtual void	shutDown (network::BaseSocket *socket)=0
	Override to perform a shutdown. More...

Public Member Functions inherited from dodo::threads::Thread
	Thread ()
	Constructor. More...

virtual	~Thread ()
	Destructor. More...

double	getAvgBlkInRate ()
	Get the average block in rate since thread start() More...

double	getAvgBlkOutRate ()
	Get the average block out rate since thread start() More...

double	getAvgICtx ()
	Get the average involuntary context switch rate since thread start() More...

double	getAvgMajFltRate ()
	Get the average major fault rate since thread start() More...

double	getAvgMinFltRate ()
	Get the average minor fault rate since thread start() More...

double	getAvgSysCPU ()
	Get the average system mode cpu (cpu seconds/second) since thread start() More...

double	getAvgUserCPU ()
	Get the average user mode cpu (cpu seconds/second) since thread start() More...

double	getAvgVCtx ()
	Get the average voluntary context switch rate since thread start() More...

std::thread::id	getId () const
	Get the thread id. More...

double	getLastBlkInRate ()
	Get last block in rate since last sample. More...

double	getLastBlkOutRate ()
	Get last block out rate since last sample. More...

double	getLastICtx ()
	Get involuntary context switch rate since last sample. More...

double	getLastMajFltRate ()
	Get the major fault rate since last sample. More...

double	getLastMinFltRate ()
	Get the minor fault rate since last sample. More...

double	getLastSysCPU ()
	Get the system mode cpu (cpu seconds/second) since last sample. More...

double	getLastUserCPU ()
	Get the user mode cpu (cpu seconds/second) since last sample. More...

double	getLastVCtx ()
	Get voluntary context switch rate since last sample. More...

long	getMaxRSS ()
	Get the maximum resident set size seen on the thread. More...

double	getRunTime ()
	Time, in seconds, since thread start. More...

double	getSnapDiffTime ()
	Time, in seconds, since last statistic update. More...

pid_t	getTID () const
	Return the tid. More...

void	snapRUsage ()
	Take a snapshot of the thread's resource usage. More...

void	start ()
	Start the thread. More...

void	wait ()
	Wait for the thread to join the current thread / wait for the thread to finish. More...

Protected Attributes
bool	busy_
	If true, the TCPServer is processing a request. More...

bool	has_stopped_
	If true, the TCPServer has stopped. More...

struct timeval	last_active_
	Time of last request handling. More...

TCPListener &	listener_
	The TCPListener the TCPServer is working for. More...

bool	request_stop_
	If true, the TCPServer should stop. More...

ServerState	state_
	State of the TCPServer. More...

Protected Attributes inherited from dodo::threads::Thread
struct rusage	prev_rusage_
	Previous statistics. More...

struct timeval	prev_snap_time_
	Time of previous statistics snapshot. More...

struct rusage	rusage_
	Last statistics. More...

struct timeval	snap_time_
	Time of last statistics snapshot. More...

struct timeval	start_time_
	Time Thread started. More...

std::thread *	thread_
	The std::tread object. More...

Additional Inherited Members

Detailed Description

Used in conjunction with TCPListener to implement high speed, multithreaded TCP services.

Subclass TCPServer and implement virtual

bool handShake(network::BaseSocket*, ssize_t&, ssize_t& )
bool readSocket( TCPListener::SocketWork &work, ssize_t &sent )
void shutDown( BaseSocket* )
TCPServer* addServer()

Each TCPServer is a thread that consumes work from the TCPListener. There can be multiple TCPServer threads consuming work together, and the TCPListener auto-scales TCPServers depending on the load.

A TCPServer is tied to a TCPListener, The TCPListener produces work to the pool of TCPServer, either

new sockets.
readable sockets (incoming data present).
shutdown sockets (The TCPListener is informing the pool of TCPServer objects the BaseSocket will disappear).

At any given moment, each TCPServer is in one of the TCPServer::ServerState states.

See also: TCPListener

Definition at line 56 of file tcpserver.hpp.

Member Enumeration Documentation

◆ ServerState

enum dodo::network::TCPServer::ServerState

The possible states of a TCPServer.

See also: getState()

Enumerator
ssWait	The TCPServer has entered waiting for activity or wait timeout.
ssAwoken	The TCPServer has woken up from a wait either due to an event or the wait timing out.
ssHandshake	The TCPServer is about to invoke handShake(BaseSocket*).
ssHandshakeDone	ssHandshake completed.
ssReadSocket	The TCPServer is about to invoke readSocket(BaseSocket*).
ssReadSocketDone	ssReadSocket completed.
ssShutdown	The TCPServer is about to invoke shutdown(BaseSocket*).
ssShutdownDone	ssShutdown completed.
ssReleaseWork	The TCPServer is releasing the request.
ssReleaseWorkDone	ssReleaseWork completed.

Definition at line 63 of file tcpserver.hpp.

Constructor & Destructor Documentation

◆ TCPServer()

dodo::network::TCPServer::TCPServer ( TCPListener & listener )

Construct a TCPServer for the TCPListener.

Parameters

listener TCPListener.

Definition at line 36 of file tcpserver.cpp.

References last_active_.

Member Function Documentation

◆ addServer()

virtual TCPServer* dodo::network::TCPServer::addServer ( )

pure virtual

Spawn a new TCPServer.

Returns: a pointer to a new TCPServer

Referenced by dodo::network::TCPListener::addServers(), dodo::network::TCPListener::cleanStoppedServers(), and dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ getIdleSeconds()

double dodo::network::TCPServer::getIdleSeconds ( )

Get the number of secodns the TCPServer has been idle.

Returns: The idle seconds.

Definition at line 183 of file tcpserver.cpp.

References dodo::common::getSecondDiff(), and last_active_.

Here is the call graph for this function:

◆ getRequestStop()

bool dodo::network::TCPServer::getRequestStop ( ) const

inline

Return true if the TCPServer was requested to stop.

Returns: true if the TCPServer was requested to stop.

Definition at line 156 of file tcpserver.hpp.

References request_stop_.

◆ getState()

ServerState dodo::network::TCPServer::getState ( ) const

inline

Return the current ServerState.

Returns: The current ServerState.

Definition at line 162 of file tcpserver.hpp.

◆ handShake()

virtual bool dodo::network::TCPServer::handShake	(	network::BaseSocket *	socket,
		ssize_t &	received,
		ssize_t &	sent
	)

pure virtual

Override to perform a protocol handshake.

Note that the TCP handshake has already taken place, and handShake() will only be called for new sockets.

Parameters

socket	A pointer to the socket to handshake. If this returns false,. the socket will be closed.
received	The number of bytes received by the call.
sent	The number of bytes sent by the call.

Returns: true if the handshake succeeded.

Referenced by run().

Here is the caller graph for this function:

◆ hasStopped()

bool dodo::network::TCPServer::hasStopped ( ) const

inline

Return true if the TCPServer has stopped working.

Returns: True if the TCPServer has stopped on request.

Definition at line 133 of file tcpserver.hpp.

References has_stopped_.

Referenced by dodo::network::TCPListener::cleanStoppedServers().

Here is the caller graph for this function:

◆ isBusy()

bool dodo::network::TCPServer::isBusy ( ) const

inline

Return true if the TCPServer is busy.

Returns: True if busy.

Definition at line 139 of file tcpserver.hpp.

References busy_.

◆ newConnectionData()

virtual TCPConnectionData* dodo::network::TCPServer::newConnectionData ( ) const

inlinevirtual

Return a new TCPConnectionData pointer or override to return a descendant of TCPConnectionData.

Returns: the new TCPConnectionData*.

Definition at line 127 of file tcpserver.hpp.

Referenced by dodo::network::TCPListener::run().

Here is the caller graph for this function:

◆ readSocket()

virtual common::SystemError dodo::network::TCPServer::readSocket	(	TCPListener::SocketWork &	work,
		ssize_t &	sent
	)

pure virtual

Override to perform a request-response cycle.

Parameters

work	The work to perform.
sent	The number of bytes sent by the call.

Returns

common::SystemError::ecOK if all is well, the request is received completely, it is handled and a response is sent.
common::SystemError::ecEAGAIN if all is well but the data in work.data is not a complete request yet.
common::SystemError::ecECONNABORTED if the socket needs to be closed (for example by client request).

Referenced by run().

Here is the caller graph for this function:

◆ requestStop()

void dodo::network::TCPServer::requestStop ( )

inline

Set the request_stop_ flag, this call returns immediately, stopping will follow.

Definition at line 150 of file tcpserver.hpp.

References request_stop_.

◆ run()

void dodo::network::TCPServer::run ( )

virtual

Run the TCPServer thread.

Implements dodo::threads::Thread.

Definition at line 44 of file tcpserver.cpp.

Here is the call graph for this function:

◆ shutDown()

virtual void dodo::network::TCPServer::shutDown ( network::BaseSocket * socket )

pure virtual

Override to perform a shutdown.

Parameters

socket The socket to work on.

Referenced by run().

Here is the caller graph for this function:

Field Documentation

◆ busy_

bool dodo::network::TCPServer::busy_

protected

If true, the TCPServer is processing a request.

Definition at line 184 of file tcpserver.hpp.

Referenced by isBusy(), and run().

◆ has_stopped_

bool dodo::network::TCPServer::has_stopped_

protected

If true, the TCPServer has stopped.

Definition at line 179 of file tcpserver.hpp.

Referenced by hasStopped(), and run().

◆ last_active_

struct timeval dodo::network::TCPServer::last_active_

protected

Time of last request handling.

Definition at line 189 of file tcpserver.hpp.

Referenced by getIdleSeconds(), run(), and TCPServer().

◆ listener_

TCPListener& dodo::network::TCPServer::listener_

protected

The TCPListener the TCPServer is working for.

Definition at line 162 of file tcpserver.hpp.

Referenced by run().

◆ request_stop_

bool dodo::network::TCPServer::request_stop_

protected

If true, the TCPServer should stop.

Definition at line 174 of file tcpserver.hpp.

Referenced by getRequestStop(), requestStop(), and run().

◆ state_

ServerState dodo::network::TCPServer::state_

protected

State of the TCPServer.

Definition at line 194 of file tcpserver.hpp.

Referenced by run().

The documentation for this class was generated from the following files:

src/include/network/tcpserver.hpp
src/lib/network/tcpserver.cpp

Public Types

Public Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Member Enumeration Documentation

◆ ServerState

Constructor & Destructor Documentation

◆ TCPServer()

Member Function Documentation

◆ addServer()

◆ getIdleSeconds()

◆ getRequestStop()

◆ getState()

◆ handShake()

◆ hasStopped()

◆ isBusy()

◆ newConnectionData()

◆ readSocket()

◆ requestStop()

◆ run()

◆ shutDown()

Field Documentation

◆ busy_

◆ has_stopped_

◆ last_active_

◆ listener_

◆ request_stop_

◆ state_
