#include <thread.hpp>

Inheritance diagram for dodo::threads::Thread:

[legend]

Collaboration diagram for dodo::threads::Thread:

[legend]

Public Member Functions
	Thread ()
	Constructor. More...

virtual	~Thread ()
	Destructor. More...

double	getAvgBlkInRate ()
	Get the average block in rate since thread start() More...

double	getAvgBlkOutRate ()
	Get the average block out rate since thread start() More...

double	getAvgICtx ()
	Get the average involuntary context switch rate since thread start() More...

double	getAvgMajFltRate ()
	Get the average major fault rate since thread start() More...

double	getAvgMinFltRate ()
	Get the average minor fault rate since thread start() More...

double	getAvgSysCPU ()
	Get the average system mode cpu (cpu seconds/second) since thread start() More...

double	getAvgUserCPU ()
	Get the average user mode cpu (cpu seconds/second) since thread start() More...

double	getAvgVCtx ()
	Get the average voluntary context switch rate since thread start() More...

std::thread::id	getId () const
	Get the thread id. More...

double	getLastBlkInRate ()
	Get last block in rate since last sample. More...

double	getLastBlkOutRate ()
	Get last block out rate since last sample. More...

double	getLastICtx ()
	Get involuntary context switch rate since last sample. More...

double	getLastMajFltRate ()
	Get the major fault rate since last sample. More...

double	getLastMinFltRate ()
	Get the minor fault rate since last sample. More...

double	getLastSysCPU ()
	Get the system mode cpu (cpu seconds/second) since last sample. More...

double	getLastUserCPU ()
	Get the user mode cpu (cpu seconds/second) since last sample. More...

double	getLastVCtx ()
	Get voluntary context switch rate since last sample. More...

long	getMaxRSS ()
	Get the maximum resident set size seen on the thread. More...

double	getRunTime ()
	Time, in seconds, since thread start. More...

double	getSnapDiffTime ()
	Time, in seconds, since last statistic update. More...

pid_t	getTID () const
	Return the tid. More...

void	snapRUsage ()
	Take a snapshot of the thread's resource usage. More...

void	start ()
	Start the thread. More...

void	wait ()
	Wait for the thread to join the current thread / wait for the thread to finish. More...

Protected Member Functions
virtual void	run ()=0
	Decsendants must override the run function. More...

Protected Attributes
struct rusage	prev_rusage_
	Previous statistics. More...

struct timeval	prev_snap_time_
	Time of previous statistics snapshot. More...

struct rusage	rusage_
	Last statistics. More...

struct timeval	snap_time_
	Time of last statistics snapshot. More...

struct timeval	start_time_
	Time Thread started. More...

std::thread *	thread_
	The std::tread object. More...

Static Private Member Functions
static void *	thread_method (void *context)
	Posix thread method - calls dodo::threads::Thread:::run(). More...

Private Attributes
pid_t	tid_
	The linux tid. More...

Detailed Description

Abstract Thread class.

Inherit and implement pure virtual run() to run threaded code.

Definition at line 38 of file thread.hpp.

Constructor & Destructor Documentation

◆ Thread()

dodo::threads::Thread::Thread ( )

Constructor.

Definition at line 45 of file thread.cpp.

References prev_rusage_, prev_snap_time_, rusage_, snap_time_, and start_time_.

◆ ~Thread()

dodo::threads::Thread::~Thread ( )

virtual

Destructor.

Definition at line 54 of file thread.cpp.

References thread_.

Member Function Documentation

◆ getAvgBlkInRate()

double dodo::threads::Thread::getAvgBlkInRate ( )

Get the average block in rate since thread start()

Returns: that rate.

Definition at line 96 of file thread.cpp.

References getRunTime(), and rusage_.

Here is the call graph for this function:

◆ getAvgBlkOutRate()

double dodo::threads::Thread::getAvgBlkOutRate ( )

Get the average block out rate since thread start()

Returns: that rate.

Definition at line 100 of file thread.cpp.

References getRunTime(), and rusage_.

Here is the call graph for this function:

◆ getAvgICtx()

double dodo::threads::Thread::getAvgICtx ( )

Get the average involuntary context switch rate since thread start()

Returns: that rate.

Definition at line 108 of file thread.cpp.

References getRunTime(), and rusage_.

Here is the call graph for this function:

◆ getAvgMajFltRate()

double dodo::threads::Thread::getAvgMajFltRate ( )

Get the average major fault rate since thread start()

Returns: that rate.

Definition at line 92 of file thread.cpp.

References getRunTime(), and rusage_.

Here is the call graph for this function:

◆ getAvgMinFltRate()

double dodo::threads::Thread::getAvgMinFltRate ( )

Get the average minor fault rate since thread start()

Returns: that rate.

Definition at line 88 of file thread.cpp.

References getRunTime(), and rusage_.

Here is the call graph for this function:

◆ getAvgSysCPU()

double dodo::threads::Thread::getAvgSysCPU ( )

Get the average system mode cpu (cpu seconds/second) since thread start()

Returns: that utilization.

Definition at line 84 of file thread.cpp.

References getRunTime(), and rusage_.

Here is the call graph for this function:

◆ getAvgUserCPU()

double dodo::threads::Thread::getAvgUserCPU ( )

Get the average user mode cpu (cpu seconds/second) since thread start()

Returns: that utilization.

Definition at line 80 of file thread.cpp.

References getRunTime(), and rusage_.

Here is the call graph for this function:

◆ getAvgVCtx()

double dodo::threads::Thread::getAvgVCtx ( )

Get the average voluntary context switch rate since thread start()

Returns: that rate.

Definition at line 104 of file thread.cpp.

References getRunTime(), and rusage_.

Here is the call graph for this function:

◆ getId()

std::thread::id dodo::threads::Thread::getId ( ) const

Get the thread id.

Returns: that id.

Definition at line 75 of file thread.cpp.

References thread_.

◆ getLastBlkInRate()

double dodo::threads::Thread::getLastBlkInRate ( )

Get last block in rate since last sample.

Returns: that rate.

Definition at line 136 of file thread.cpp.

References getSnapDiffTime(), prev_rusage_, and rusage_.

Referenced by dodo::network::TCPListener::logStats().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getLastBlkOutRate()

double dodo::threads::Thread::getLastBlkOutRate ( )

Get last block out rate since last sample.

Returns: that rate.

Definition at line 141 of file thread.cpp.

References getSnapDiffTime(), prev_rusage_, and rusage_.

Referenced by dodo::network::TCPListener::logStats().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getLastICtx()

double dodo::threads::Thread::getLastICtx ( )

Get involuntary context switch rate since last sample.

Returns: that rate.

Definition at line 151 of file thread.cpp.

References getSnapDiffTime(), prev_rusage_, and rusage_.

Referenced by dodo::network::TCPListener::logStats().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getLastMajFltRate()

double dodo::threads::Thread::getLastMajFltRate ( )

Get the major fault rate since last sample.

Returns: that rate.

Definition at line 131 of file thread.cpp.

References getSnapDiffTime(), prev_rusage_, and rusage_.

Referenced by dodo::network::TCPListener::logStats().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getLastMinFltRate()

double dodo::threads::Thread::getLastMinFltRate ( )

Get the minor fault rate since last sample.

Returns: that rate.

Definition at line 126 of file thread.cpp.

References getSnapDiffTime(), prev_rusage_, and rusage_.

Referenced by dodo::network::TCPListener::logStats().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getLastSysCPU()

double dodo::threads::Thread::getLastSysCPU ( )

Get the system mode cpu (cpu seconds/second) since last sample.

Returns: that utilization.

Definition at line 121 of file thread.cpp.

References getSnapDiffTime(), prev_rusage_, and rusage_.

Referenced by dodo::network::TCPListener::logStats().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getLastUserCPU()

double dodo::threads::Thread::getLastUserCPU ( )

Get the user mode cpu (cpu seconds/second) since last sample.

Returns: that utilization.

Definition at line 116 of file thread.cpp.

References getSnapDiffTime(), prev_rusage_, and rusage_.

Referenced by dodo::network::TCPListener::logStats().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getLastVCtx()

double dodo::threads::Thread::getLastVCtx ( )

Get voluntary context switch rate since last sample.

Returns: that rate.

Definition at line 146 of file thread.cpp.

References getSnapDiffTime(), prev_rusage_, and rusage_.

Referenced by dodo::network::TCPListener::logStats().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getMaxRSS()

long dodo::threads::Thread::getMaxRSS ( )

Get the maximum resident set size seen on the thread.

Returns: that size.

Definition at line 112 of file thread.cpp.

References rusage_.

Referenced by dodo::network::TCPListener::logStats().

Here is the caller graph for this function:

◆ getRunTime()

double dodo::threads::Thread::getRunTime ( )

Time, in seconds, since thread start.

Returns: that time.

Definition at line 156 of file thread.cpp.

References dodo::common::getSecondDiff(), snap_time_, and start_time_.

Referenced by getAvgBlkInRate(), getAvgBlkOutRate(), getAvgICtx(), getAvgMajFltRate(), getAvgMinFltRate(), getAvgSysCPU(), getAvgUserCPU(), and getAvgVCtx().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getSnapDiffTime()

double dodo::threads::Thread::getSnapDiffTime ( )

Time, in seconds, since last statistic update.

Returns: that time.

Definition at line 160 of file thread.cpp.

References dodo::common::getSecondDiff(), prev_snap_time_, and snap_time_.

Referenced by getLastBlkInRate(), getLastBlkOutRate(), getLastICtx(), getLastMajFltRate(), getLastMinFltRate(), getLastSysCPU(), getLastUserCPU(), and getLastVCtx().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getTID()

pid_t dodo::threads::Thread::getTID ( ) const

inline

Return the tid.

Returns: the TID.

Definition at line 190 of file thread.hpp.

References tid_.

Referenced by dodo::network::TCPListener::cleanStoppedServers().

Here is the caller graph for this function:

◆ run()

virtual void dodo::threads::Thread::run ( )

protectedpure virtual

Decsendants must override the run function.

Implemented in dodo::network::TCPListener, dodo::network::TCPServer, and dodo::network::TCPListenerTimer.

Referenced by thread_method().

Here is the caller graph for this function:

◆ snapRUsage()

void dodo::threads::Thread::snapRUsage ( )

Take a snapshot of the thread's resource usage.

Definition at line 68 of file thread.cpp.

References prev_rusage_, prev_snap_time_, rusage_, and snap_time_.

Referenced by dodo::network::TCPListener::logStats(), dodo::network::TCPServer::run(), and thread_method().

Here is the caller graph for this function:

◆ start()

void dodo::threads::Thread::start ( )

Start the thread.

Definition at line 58 of file thread.cpp.

References thread_, and thread_method().

Referenced by dodo::network::TCPListener::addServers(), dodo::network::TCPListener::cleanStoppedServers(), and dodo::network::TCPListener::run().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ thread_method()

void * dodo::threads::Thread::thread_method ( void * context )

staticprivate

Posix thread method - calls dodo::threads::Thread:::run().

Parameters

context Is used to pass a Thread* so that its run() method can be called.

Returns: nullptr (always)

Definition at line 33 of file thread.cpp.

References run(), snapRUsage(), start_time_, and tid_.

Referenced by start().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ wait()

void dodo::threads::Thread::wait ( )

Wait for the thread to join the current thread / wait for the thread to finish.

Definition at line 64 of file thread.cpp.

References thread_.

Referenced by dodo::network::TCPListener::cleanStoppedServers().

Here is the caller graph for this function:

Field Documentation

◆ prev_rusage_

struct rusage dodo::threads::Thread::prev_rusage_

protected

Previous statistics.

Definition at line 222 of file thread.hpp.

Referenced by getLastBlkInRate(), getLastBlkOutRate(), getLastICtx(), getLastMajFltRate(), getLastMinFltRate(), getLastSysCPU(), getLastUserCPU(), getLastVCtx(), snapRUsage(), and Thread().

◆ prev_snap_time_

struct timeval dodo::threads::Thread::prev_snap_time_

protected

Time of previous statistics snapshot.

Definition at line 212 of file thread.hpp.

Referenced by getSnapDiffTime(), snapRUsage(), and Thread().

◆ rusage_

struct rusage dodo::threads::Thread::rusage_

protected

Last statistics.

Definition at line 227 of file thread.hpp.

Referenced by getAvgBlkInRate(), getAvgBlkOutRate(), getAvgICtx(), getAvgMajFltRate(), getAvgMinFltRate(), getAvgSysCPU(), getAvgUserCPU(), getAvgVCtx(), getLastBlkInRate(), getLastBlkOutRate(), getLastICtx(), getLastMajFltRate(), getLastMinFltRate(), getLastSysCPU(), getLastUserCPU(), getLastVCtx(), getMaxRSS(), snapRUsage(), and Thread().

◆ snap_time_

struct timeval dodo::threads::Thread::snap_time_

protected

Time of last statistics snapshot.

Definition at line 217 of file thread.hpp.

Referenced by getRunTime(), getSnapDiffTime(), snapRUsage(), and Thread().

◆ start_time_

struct timeval dodo::threads::Thread::start_time_

protected

Time Thread started.

Definition at line 207 of file thread.hpp.

Referenced by getRunTime(), Thread(), and thread_method().

◆ thread_

std::thread* dodo::threads::Thread::thread_

protected

The std::tread object.

Definition at line 202 of file thread.hpp.

Referenced by getId(), start(), wait(), and ~Thread().

◆ tid_

pid_t dodo::threads::Thread::tid_

private

The linux tid.

Definition at line 241 of file thread.hpp.

Referenced by getTID(), and thread_method().

The documentation for this class was generated from the following files:

src/include/threads/thread.hpp
src/lib/threads/thread.cpp

Public Member Functions

Protected Member Functions

Protected Attributes

Static Private Member Functions

Private Attributes

Detailed Description

Constructor & Destructor Documentation

◆ Thread()

◆ ~Thread()

Member Function Documentation

◆ getAvgBlkInRate()

◆ getAvgBlkOutRate()

◆ getAvgICtx()

◆ getAvgMajFltRate()

◆ getAvgMinFltRate()

◆ getAvgSysCPU()

◆ getAvgUserCPU()

◆ getAvgVCtx()

◆ getId()

◆ getLastBlkInRate()

◆ getLastBlkOutRate()

◆ getLastICtx()

◆ getLastMajFltRate()

◆ getLastMinFltRate()

◆ getLastSysCPU()

◆ getLastUserCPU()

◆ getLastVCtx()

◆ getMaxRSS()

◆ getRunTime()

◆ getSnapDiffTime()

◆ getTID()

◆ run()

◆ snapRUsage()

◆ start()

◆ thread_method()

◆ wait()

Field Documentation

◆ prev_rusage_

◆ prev_snap_time_

◆ rusage_

◆ snap_time_

◆ start_time_

◆ thread_

◆ tid_
