dodo::network::protocol::stomp::Frame Class Reference

A generic STOMP 1.2 frame. More...

#include <stomp.hpp>

Inheritance diagram for dodo::network::protocol::stomp::Frame:

Collaboration diagram for dodo::network::protocol::stomp::Frame:

Public Types
enum	FrameMatch { FrameMatch::NoMatch, FrameMatch::IncompleteMatch, FrameMatch::FullMatch }
	The manner in which frames match the STOMP protocol. More...
enum	Version { Version::v1_2 }
	STOMP versions. More...

Public Member Functions
virtual void	generate (common::Bytes &frame) const =0
	Generate a frame. More...
virtual FrameMatch	match (const common::Bytes &frame, std::list< std::string > &errors) const =0
	Checks how the data matches a frame specification. More...

Data Fields
const common::Bytes	command_connect { "STOMP" }
	CONNECT command. More...
const common::Bytes	command_connected { "CONNECTED" }
	CONNECTED command. More...
const common::Bytes	eol { "\n" }
	EOL sequence - use only as the protocl allows it and the extra serves no purpose. More...
const common::Bytes	header_accept_version_1_2 { "accept-version:1.2" }
	STOMP 1.2 accept header. More...

Protected Member Functions
FrameMatch	readCommand (const common::Bytes &frame, size_t &index, const common::Bytes &command) const
	Read a command from a frame. More...

Detailed Description

A generic STOMP 1.2 frame.

Definition at line 36 of file stomp.hpp.

Member Enumeration Documentation

FrameMatch

enum dodo::network::protocol::stomp::Frame::FrameMatch

strong

The manner in which frames match the STOMP protocol.

Enumerator
NoMatch	Mismatch.
IncompleteMatch	Match, but incomplete.
FullMatch	Complete match.

Definition at line 54 of file stomp.hpp.

Version

enum dodo::network::protocol::stomp::Frame::Version

strong

STOMP versions.

Only the latest 1.2 version is supported.

Enumerator
v1_2	STOMP 1.2.

Definition at line 63 of file stomp.hpp.

Member Function Documentation

generate()

virtual void dodo::network::protocol::stomp::Frame::generate ( common::Bytes &  frame ) const

pure virtual

Generate a frame.

Parameters

frame

The generation destination, which is overwritten.

Implemented in dodo::network::protocol::stomp::Connected, and dodo::network::protocol::stomp::Connect.

match()

virtual FrameMatch dodo::network::protocol::stomp::Frame::match ( const common::Bytes &  frame, std::list< std::string > &  errors  ) const

pure virtual

Checks how the data matches a frame specification.

Parameters

frame	The frame / common::Bytes to match against.
errors	If returning FrameMatch::NoMatch, one or more errors.

Returns

FrameMatch::IncompleteMatch if the frame matches but is incomplete, FrameMatch::FullMatch if it matches completely.

Implemented in dodo::network::protocol::stomp::Connect.

readCommand()

Frame::FrameMatch dodo::network::protocol::stomp::Frame::readCommand ( const common::Bytes &  frame, size_t &  index, const common::Bytes &  command  ) const

protected

Read a command from a frame.

Parameters

frame	The (incomplete) frame
index	The index into fame (0 for commands).
command	The command to read.

Returns

FrameMatch::IncompleteMatch if the frame matches but is incomplete, FrameMatch::FullMatch if it matches completely.

Definition at line 32 of file stomp.cpp.

References FullMatch, dodo::common::Bytes::getOctet(), dodo::common::Bytes::getSize(), IncompleteMatch, and NoMatch.

Referenced by dodo::network::protocol::stomp::Connect::match().

Here is the call graph for this function:

Here is the caller graph for this function:

Field Documentation

command_connect

const common::Bytes dodo::network::protocol::stomp::Frame::command_connect { "STOMP" }

CONNECT command.

Definition at line 43 of file stomp.hpp.

Referenced by dodo::network::protocol::stomp::Connect::generate(), and dodo::network::protocol::stomp::Connect::match().

command_connected

const common::Bytes dodo::network::protocol::stomp::Frame::command_connected { "CONNECTED" }

CONNECTED command.

Definition at line 46 of file stomp.hpp.

eol

const common::Bytes dodo::network::protocol::stomp::Frame::eol { "\n" }

EOL sequence - use only
as the protocl allows it and the extra
serves no purpose.

Definition at line 40 of file stomp.hpp.

Referenced by dodo::network::protocol::stomp::Connect::generate().

header_accept_version_1_2

const common::Bytes dodo::network::protocol::stomp::Frame::header_accept_version_1_2 { "accept-version:1.2" }

STOMP 1.2 accept header.

Definition at line 49 of file stomp.hpp.

Referenced by dodo::network::protocol::stomp::Connect::generate().

---

The documentation for this class was generated from the following files:

• src/include/network/protocol/stomp/stomp.hpp
• src/lib/network/protocol/stomp/stomp.cpp
