dodo::network::protocol::stomp::Connected Class Reference

A STOMP CONNECTED frame. More...

#include <stomp.hpp>

Inheritance diagram for dodo::network::protocol::stomp::Connected:

Collaboration diagram for dodo::network::protocol::stomp::Connected:

Public Member Functions
	Connected (const Version &version)
	Constructor. More...
virtual void	generate (common::Bytes &frame) const
	Generate a CONNECTED frame. More...
Public Member Functions inherited from dodo::network::protocol::stomp::Frame
virtual FrameMatch	match (const common::Bytes &frame, std::list< std::string > &errors) const =0
	Checks how the data matches a frame specification. More...

Protected Attributes
size_t	heartbeat_in_ms_
	Desired incoming heartbeat delay in milliseconds. More...
size_t	heartbeat_out_ms_
	Offered outgoing heartbeat delay in milliseconds. More...
std::string	server_
	The server id. More...
std::string	session_id_
	The session id. More...
Version	version_
	STOMP protocol version required in CONNECT handshake. More...

Additional Inherited Members
Public Types inherited from dodo::network::protocol::stomp::Frame
enum	FrameMatch { FrameMatch::NoMatch, FrameMatch::IncompleteMatch, FrameMatch::FullMatch }
	The manner in which frames match the STOMP protocol. More...
enum	Version { Version::v1_2 }
	STOMP versions. More...
Data Fields inherited from dodo::network::protocol::stomp::Frame
const common::Bytes	command_connect { "STOMP" }
	CONNECT command. More...
const common::Bytes	command_connected { "CONNECTED" }
	CONNECTED command. More...
const common::Bytes	eol { "\n" }
	EOL sequence - use only as the protocl allows it and the extra serves no purpose. More...
const common::Bytes	header_accept_version_1_2 { "accept-version:1.2" }
	STOMP 1.2 accept header. More...
Protected Member Functions inherited from dodo::network::protocol::stomp::Frame
FrameMatch	readCommand (const common::Bytes &frame, size_t &index, const common::Bytes &command) const
	Read a command from a frame. More...

Detailed Description

A STOMP CONNECTED frame.

Definition at line 203 of file stomp.hpp.

Constructor & Destructor Documentation

Connected()

dodo::network::protocol::stomp::Connected::Connected ( const Version &  version )

inline

Constructor.

Parameters

version

The STOMP protocol version.

Definition at line 210 of file stomp.hpp.

Member Function Documentation

generate()

virtual void dodo::network::protocol::stomp::Connected::generate ( common::Bytes &  frame ) const

virtual

Generate a CONNECTED frame.

Parameters

frame

The generation destination, which is overwritten.

Implements dodo::network::protocol::stomp::Frame.

Field Documentation

heartbeat_in_ms_

size_t dodo::network::protocol::stomp::Connected::heartbeat_in_ms_

protected

Desired incoming heartbeat delay in milliseconds.

Definition at line 231 of file stomp.hpp.

heartbeat_out_ms_

size_t dodo::network::protocol::stomp::Connected::heartbeat_out_ms_

protected

Offered outgoing heartbeat delay in milliseconds.

Definition at line 228 of file stomp.hpp.

server_

std::string dodo::network::protocol::stomp::Connected::server_

protected

The server id.

Definition at line 237 of file stomp.hpp.

session_id_

std::string dodo::network::protocol::stomp::Connected::session_id_

protected

The session id.

Definition at line 234 of file stomp.hpp.

version_

Version dodo::network::protocol::stomp::Connected::version_

protected

STOMP protocol version required in CONNECT handshake.

Definition at line 225 of file stomp.hpp.

---

The documentation for this class was generated from the following file:

• src/include/network/protocol/stomp/stomp.hpp
