A persistent, multi-threaded key-value store backed by sqlite3 database (file). More...

#include <kvstore.hpp>

Collaboration diagram for dodo::persist::KVStore:

[legend]

Data Structures
struct	MetaData
	Meta data concerning the key. More...

Public Member Functions
	KVStore (const std::filesystem::path &path)
	Create the KVStore object against the path. More...

	~KVStore ()
	Destructor, cleanup sync and close the SQLLite database. More...

void	checkpoint ()
	Sync all to disk - issue a SQLite full checkpoint. More...

void	commitTransaction ()
	Commit a transaction. More...

bool	deleteKey (const std::string &key)
	Delete the key or return false if the key does not exist. More...

std::string	ensureWithDefault (const std::string &key, const std::string &def)
	If the key does not exist, create it with the default and return the default. More...

double	ensureWithDefault (const std::string &key, double &def)
	If the key does not exist, create it with the default and return the default. More...

int64_t	ensureWithDefault (const std::string &key, int64_t &def)
	If the key does not exist, create it with the default and return the default. More...

bool	exists (const std::string &key) const
	Check if the key exists. More...

void	filterKeys (std::list< std::string > &keys, const std::string &filter) const
	Return a list of keys that match the filter. More...

MetaData	getMetaData (const std::string &key) const
	Get MetaData for the key. More...

bool	getValue (const std::string &key, common::Bytes &value) const
	If the key exists, returns true and copies (overwrites) data to the Bytes. More...

bool	getValue (const std::string &key, double &value) const
	If the key exists, returns true and sets the value parameter. More...

bool	getValue (const std::string &key, int64_t &value) const
	If the key exists, returns true and sets the value parameter. More...

bool	getValue (const std::string &key, std::string &value) const
	If the key exists, returns true and sets the value parameter. More...

bool	insertKey (const std::string &key, const common::Bytes &value)
	Insert a (key, Bytes) pair. More...

bool	insertKey (const std::string &key, const double &value)
	Insert a (key, double) pair. More...

bool	insertKey (const std::string &key, const int64_t &value)
	Insert a (key, int64_t) pair. More...

bool	insertKey (const std::string &key, const std::string &value)
	Insert a (key, string) pair. More...

void	optimize ()
	Optimzime, preferably called after workload and implicitly called by the destructor. More...

void	rollbackTransaction ()
	Rollback a transaction. More...

bool	setKey (const std::string &key, const common::Bytes &value)
	Set the binary data/Bytes value of an existing key. More...

bool	setKey (const std::string &key, const double &value)
	Set the double value of an existing key. More...

bool	setKey (const std::string &key, const int64_t &value)
	Set the int64_t value of an existing key. More...

bool	setKey (const std::string &key, const std::string &value)
	Set the string value of an existing key. More...

void	startTransaction ()
	Start a transaction. More...

void	vacuum ()
	Vaccum - clean and defragment, which may increase efficiency after heavy deletion and/or modification. More...

Protected Member Functions
void	createSchema ()
	Create the SQLite schema. More...

void	prepareSQL ()
	Prepare all SQL statements. More...

Protected Attributes
sqlite::Database *	db_
	The database handle. More...

std::filesystem::path	path_
	The filesystem path to the kvstore. More...

sqlite::DML *	stmt_delete_
	Delete key pair statement handle. More...

sqlite::Query *	stmt_exists_
	check key existence statement handle. More...

sqlite::Query *	stmt_getvalue_
	Get-value-for-key statement handle. More...

sqlite::DML *	stmt_insert_
	Insert key pair statement handle. More...

sqlite::Query *	stmt_key_filter_
	Key filter statement handle. More...

sqlite::Query *	stmt_key_value_filter_
	Key + value filter statement handle. More...

sqlite::Query *	stmt_metadata_
	Get metadata statement handle. More...

sqlite::DML *	stmt_update_
	Update key pair statement handle. More...

Detailed Description

A persistent, multi-threaded key-value store backed by sqlite3 database (file).

If each thread uses its own KVStore object, no explicit synchronization is required between the threads. Cluster filesystems are not supported - two processes can only write to a single SQLite file if the processes run on the same host.

The KVStore is backed by the kvstore table. In SQLite, values in the same column can have different data types, so the table can store values of any of the supported data types:

DataType	C++ type	SQLite type
dtInteger	int64_t	SQLITE_INTEGER
dtFloat	double	SQLITE_FLOAT
dtText	std::string	SQLITE3_TEXT
dtBlob	common::Bytes	SQLITE_BLOB
dtUnknown	used to indicate the unknown dataType of a non-existing key

In typical use the code is aware of the datatype of a key, so typical use would be

persist::KVStore store("mystore.db");
store.insertKey( "pi", 3.14 );         // insert as a double value
double pi = store.asDouble( "pi" );    // retrieve as a double value as we know it is a double.

Moreover, SQLite will convert (CAST) between types where possible, but revert to defaults when it can't. For example,

store.insertKey( "key", "value" );

cout << store.asInteger( "key" ) << endl;

will output 0 as the string "value" does not convert to an integer. Use getMetaData to check if a key is of the expected DataType.

It is also possible to store dodo::common::Bytes (dtBlob / SQLITE_BLOB) types.

The SQLite database is initailized in WAL mode for performance. Make sure to use transactions to group bulk insertKey or setKey as that is much faster.

The examples/kvstore/kvstore.cpp is a simple speed test using a KVStore:

#include <iostream>

#include <dodo.hpp>

using namespace dodo;
using namespace std;


#define KEY_SPACE 160000
#define KEY_MAX_LENGTH 64
#define DATA_MAX_LENGTH 128
#define MAX_SETKEYS 1000

set<string> keys;

string random_string( size_t length ) {
  auto randchar = []() -> char
  {
      const char charset[] =
      "0123456789"
      "ABCDEFGHIJKLMNOPQRSTUVWXYZ"
      "abcdefghijklmnopqrstuvwxyz";
      const size_t max_index = (sizeof(charset) - 1);
      return charset[ rand() % max_index ];
  };
  string str(length,0);
  generate_n( str.begin(), length, randchar );
  return str;
}

void setupTestData() {
  for ( size_t i = 0; i < KEY_SPACE; i++ ) {
    keys.insert( random_string( rand() % KEY_MAX_LENGTH ) );
  }
}

void insertKeys( persist::KVStore &store ) {
  store.startTransaction();
  for ( const auto &k : keys ) {
    store.insertKey( k, random_string( rand() % DATA_MAX_LENGTH ) );
  }
  store.commitTransaction();
}

void fetchKeys( persist::KVStore &store ) {
  for ( const auto &k : keys ) {
    string value = "";
    if ( ! store.getValue( k, value ) ) throw runtime_error( "key not found - cannot be!" );
  }
}

void updateKeys( persist::KVStore &store ) {
  size_t count = 0;
  for ( const auto &k : keys ) {
    store.setKey( k, random_string( rand() % DATA_MAX_LENGTH ) );
    if ( ++count > MAX_SETKEYS ) break;
  }
}

int main() {

  try {
    dodo::initLibrary();
    persist::KVStore store( "kvstore.db" );
    common::StopWatch sw;
    double time_setup = 0.0;
    double time_insert = 0.0;
    double time_checkpoint = 0.0;
    double time_fetch = 0.0;
    double time_update = 0.0;
    sw.start();
    setupTestData();
    time_setup = sw.restart();
    insertKeys( store );
    time_insert = sw.restart();
    store.checkpoint();
    time_checkpoint = sw.restart();
    fetchKeys( store );
    time_fetch = sw.restart();
    updateKeys( store );
    time_update = sw.stop();
    cout << "setup " << time_setup << "s" << endl;
    cout << "insertKey (bulk) " << time_insert << "s" << endl;
    cout << "checkpoint " << time_checkpoint << "s" << endl;
    cout << "getValue " << time_fetch << "s" << endl;
    cout << "setKey (single) " << time_update << "s" << endl;
    cout << static_cast<double>(keys.size())/time_insert << " insertKey (bulk) per second" << endl;
    cout << static_cast<double>(keys.size())/time_fetch << " getValue per second" << endl;
    cout << static_cast<double>(MAX_SETKEYS)/time_update << " setKey (single) per second" << endl;
  }
  catch ( const runtime_error  &e ) {
    cerr << e.what() << endl;
  }
  std::remove( "kvstore.db" );
  dodo::closeLibrary();
  return 0;
}

Definition at line 77 of file kvstore.hpp.

Constructor & Destructor Documentation

◆ KVStore()

dodo::persist::KVStore::KVStore ( const std::filesystem::path & path )

Create the KVStore object against the path.

If the KVStore does not exist yet, it is created. If it already exists, it is opened.

Parameters

path	The filesystem path of the KVStore file.

Definition at line 34 of file kvstore.cpp.

References createSchema(), db_, path_, prepareSQL(), stmt_delete_, stmt_exists_, stmt_getvalue_, stmt_insert_, stmt_key_filter_, stmt_key_value_filter_, stmt_metadata_, and stmt_update_.

Here is the call graph for this function:

◆ ~KVStore()

dodo::persist::KVStore::~KVStore ( )

Destructor, cleanup sync and close the SQLLite database.

Definition at line 50 of file kvstore.cpp.

References checkpoint(), db_, optimize(), stmt_delete_, stmt_exists_, stmt_getvalue_, stmt_insert_, stmt_key_filter_, stmt_key_value_filter_, stmt_metadata_, and stmt_update_.

Here is the call graph for this function:

Member Function Documentation

◆ checkpoint()

void dodo::persist::KVStore::checkpoint ( )

Sync all to disk - issue a SQLite full checkpoint.

Definition at line 64 of file kvstore.cpp.

References dodo::persist::sqlite::Database::checkPointFull(), and db_.

Referenced by ~KVStore().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ commitTransaction()

void dodo::persist::KVStore::commitTransaction ( )

Commit a transaction.

Throws a dodo::common::Exception when no transaction has started.

Definition at line 68 of file kvstore.cpp.

References dodo::persist::sqlite::Database::commit(), and db_.

Here is the call graph for this function:

◆ createSchema()

void dodo::persist::KVStore::createSchema ( )

protected

Create the SQLite schema.

Definition at line 72 of file kvstore.cpp.

References db_, dodo::persist::sqlite::DDL::execute(), dodo::persist::sqlite::Statement::prepare(), and dodo::persist::sqlite::Query::step().

Referenced by KVStore().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ deleteKey()

bool dodo::persist::KVStore::deleteKey ( const std::string & key )

Delete the key or return false if the key does not exist.

Parameters

key The key.

Returns: True if the key existed.

Definition at line 90 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::DML::execute(), dodo::persist::sqlite::Statement::reset(), and stmt_delete_.

Here is the call graph for this function:

◆ ensureWithDefault() [1/3]

std::string dodo::persist::KVStore::ensureWithDefault	(	const std::string &	key,
		const std::string &	def
	)

If the key does not exist, create it with the default and return the default.

If the key exists, return its value (which may not be the default).

Parameters

key	The key.
def	The string value for the key if it does not exist.

Returns: The key value.

Definition at line 97 of file kvstore.cpp.

References getValue(), and insertKey().

Here is the call graph for this function:

◆ ensureWithDefault() [2/3]

double dodo::persist::KVStore::ensureWithDefault	(	const std::string &	key,
		double &	def
	)

If the key does not exist, create it with the default and return the default.

If the key exists, return its value (which may not be the default).

Parameters

key	The key.
def	The double value for the key if it does not exist.

Returns: The key value.

Definition at line 107 of file kvstore.cpp.

References getValue(), and insertKey().

Here is the call graph for this function:

◆ ensureWithDefault() [3/3]

int64_t dodo::persist::KVStore::ensureWithDefault	(	const std::string &	key,
		int64_t &	def
	)

If the key does not exist, create it with the default and return the default.

If the key exists, return its value (which may not be the default).

Parameters

key	The key.
def	The int64_t value for the key if it does not exist.

Returns: The key value.

Definition at line 117 of file kvstore.cpp.

References getValue(), and insertKey().

Here is the call graph for this function:

◆ exists()

bool dodo::persist::KVStore::exists ( const std::string & key ) const

Check if the key exists.

Unless the value is not required , it is more efficient to get the value in one go by calling the getString(), getDouble(), getInt64() and getData() members, which return false if the key does not exist.

Parameters

key	The key to check for.

Returns: False if the key does not exist.

Definition at line 127 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::Query::getInt(), dodo::persist::sqlite::Statement::reset(), dodo::persist::sqlite::Query::step(), and stmt_exists_.

Here is the call graph for this function:

◆ filterKeys()

void dodo::persist::KVStore::filterKeys	(	std::list< std::string > &	keys,
		const std::string &	filter
	)		const

Return a list of keys that match the filter.

Parameters

keys	The list that receives the keys. The list is cleared before assigning keys so it may turn up empty if the filter matches no keys.
filter	The SQL-style case-sensitive filter as in 'match', 'match'

Definition at line 135 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::Query::getText(), dodo::persist::sqlite::Statement::reset(), dodo::persist::sqlite::Query::step(), and stmt_key_filter_.

Here is the call graph for this function:

◆ getMetaData()

KVStore::MetaData dodo::persist::KVStore::getMetaData ( const std::string & key ) const

Get MetaData for the key.

Parameters

key The key.

Returns: the MetaData for the key.

Definition at line 144 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::Query::getDataType(), dodo::persist::sqlite::Query::getDouble(), dodo::persist::sqlite::Query::getInt64(), dodo::persist::KVStore::MetaData::last_modified, dodo::persist::sqlite::Statement::reset(), dodo::persist::sqlite::Query::step(), stmt_metadata_, dodo::persist::KVStore::MetaData::type, and dodo::persist::KVStore::MetaData::update_count.

Here is the call graph for this function:

◆ getValue() [1/4]

bool dodo::persist::KVStore::getValue	(	const std::string &	key,
		common::Bytes &	value
	)		const

If the key exists, returns true and copies (overwrites) data to the Bytes.

Parameters

key	The key to get the value for.
value	The Bytes that will receive the data.

Returns: False if the key does not exist.

Definition at line 189 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::Query::getBytes(), dodo::persist::sqlite::Statement::reset(), dodo::persist::sqlite::Query::step(), and stmt_getvalue_.

Here is the call graph for this function:

◆ getValue() [2/4]

bool dodo::persist::KVStore::getValue	(	const std::string &	key,
		double &	value
	)		const

If the key exists, returns true and sets the value parameter.

Parameters

key	The key to get the value for.
value	The destination value to set.

Returns: False if the key does not exist.

Definition at line 167 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::Query::getDouble(), dodo::persist::sqlite::Statement::reset(), dodo::persist::sqlite::Query::step(), and stmt_getvalue_.

Here is the call graph for this function:

◆ getValue() [3/4]

bool dodo::persist::KVStore::getValue	(	const std::string &	key,
		int64_t &	value
	)		const

If the key exists, returns true and sets the value parameter.

Parameters

key	The key to get the value for.
value	The destination value to set.

Returns: False if the key does not exist.

Definition at line 178 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::Query::getInt64(), dodo::persist::sqlite::Statement::reset(), dodo::persist::sqlite::Query::step(), and stmt_getvalue_.

Here is the call graph for this function:

◆ getValue() [4/4]

bool dodo::persist::KVStore::getValue	(	const std::string &	key,
		std::string &	value
	)		const

If the key exists, returns true and sets the value parameter.

Parameters

key	The key to get the value for.
value	The destination value to set.

Returns: False if the key does not exist.

Definition at line 156 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::Query::getText(), dodo::persist::sqlite::Statement::reset(), dodo::persist::sqlite::Query::step(), and stmt_getvalue_.

Referenced by ensureWithDefault().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ insertKey() [1/4]

bool dodo::persist::KVStore::insertKey	(	const std::string &	key,
		const common::Bytes &	value
	)

Insert a (key, Bytes) pair.

Note that the size of the data cannot exceed INT_MAX, and exception is thrown if the Bytes is larger.

Parameters

key	The key.
value	The Bytes to insert.

Returns: True if the key was created, false if the key already exists.

Definition at line 226 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::DML::execute(), dodo::persist::sqlite::Statement::reset(), and stmt_insert_.

Here is the call graph for this function:

◆ insertKey() [2/4]

bool dodo::persist::KVStore::insertKey	(	const std::string &	key,
		const double &	value
	)

Insert a (key, double) pair.

Parameters

key	The key.
value	The double value to set.

Returns: True if the key was created, false if the key already exists.

Definition at line 208 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::DML::execute(), dodo::persist::sqlite::Statement::reset(), and stmt_insert_.

Here is the call graph for this function:

◆ insertKey() [3/4]

bool dodo::persist::KVStore::insertKey	(	const std::string &	key,
		const int64_t &	value
	)

Insert a (key, int64_t) pair.

Parameters

key	The key.
value	The int64_t value to set.

Returns: True if the key was created, false if the key already exists.

Definition at line 217 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::DML::execute(), dodo::persist::sqlite::Statement::reset(), and stmt_insert_.

Here is the call graph for this function:

◆ insertKey() [4/4]

bool dodo::persist::KVStore::insertKey	(	const std::string &	key,
		const std::string &	value
	)

Insert a (key, string) pair.

Parameters

key	The key.
value	The string value to set.

Returns: True if the key was created, false if the key already exists.

Definition at line 200 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::DML::execute(), dodo::persist::sqlite::Statement::reset(), and stmt_insert_.

Referenced by ensureWithDefault().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ optimize()

void dodo::persist::KVStore::optimize ( )

Optimzime, preferably called after workload and implicitly called by the destructor.

Definition at line 235 of file kvstore.cpp.

References db_, dodo::persist::sqlite::DDL::execute(), and dodo::persist::sqlite::Statement::prepare().

Referenced by ~KVStore().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ prepareSQL()

void dodo::persist::KVStore::prepareSQL ( )

protected

Prepare all SQL statements.

Definition at line 241 of file kvstore.cpp.

References db_, dodo::persist::sqlite::DDL::execute(), dodo::persist::sqlite::Statement::prepare(), stmt_delete_, stmt_exists_, stmt_getvalue_, stmt_insert_, stmt_key_filter_, stmt_key_value_filter_, stmt_metadata_, and stmt_update_.

Referenced by KVStore().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ rollbackTransaction()

void dodo::persist::KVStore::rollbackTransaction ( )

Rollback a transaction.

Throws a dodo::common::Exception when no transaction has started.

Definition at line 256 of file kvstore.cpp.

References db_, and dodo::persist::sqlite::Database::rollback().

Here is the call graph for this function:

◆ setKey() [1/4]

bool dodo::persist::KVStore::setKey	(	const std::string &	key,
		const common::Bytes &	value
	)

Set the binary data/Bytes value of an existing key.

The function returns false if the key does not exist.

Parameters

key	The key.
value	The Bytes to set.

Returns: True if the key exists, in which case it is also updated.

Definition at line 284 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::DML::execute(), dodo::persist::sqlite::Statement::reset(), and stmt_update_.

Here is the call graph for this function:

◆ setKey() [2/4]

bool dodo::persist::KVStore::setKey	(	const std::string &	key,
		const double &	value
	)

Set the double value of an existing key.

The function returns false if the key does not exist.

Parameters

key	The key.
value	The double value to set.

Returns: True if the key exists, in which case it is also updated.

Definition at line 268 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::DML::execute(), dodo::persist::sqlite::Statement::reset(), and stmt_update_.

Here is the call graph for this function:

◆ setKey() [3/4]

bool dodo::persist::KVStore::setKey	(	const std::string &	key,
		const int64_t &	value
	)

Set the int64_t value of an existing key.

The function returns false if the key does not exist.

Parameters

key	The key.
value	The int64_t value to set.

Returns: True if the key exists, in which case it is also updated.

Definition at line 276 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::DML::execute(), dodo::persist::sqlite::Statement::reset(), and stmt_update_.

Here is the call graph for this function:

◆ setKey() [4/4]

bool dodo::persist::KVStore::setKey	(	const std::string &	key,
		const std::string &	value
	)

Set the string value of an existing key.

The function returns false if the key does not exist.

Parameters

key	The key.
value	The string value to set.

Returns: True if the key exists, in which case it is also updated.

Definition at line 260 of file kvstore.cpp.

References dodo::persist::sqlite::DML::bind(), dodo::persist::sqlite::DML::execute(), dodo::persist::sqlite::Statement::reset(), and stmt_update_.

Here is the call graph for this function:

◆ startTransaction()

void dodo::persist::KVStore::startTransaction ( )

Start a transaction.

If insertKey or setKey calls are not inside a started transaction, each will commit automatically and indvidually, which is mach (much!) slower for bulk operations.

Definition at line 292 of file kvstore.cpp.

References db_, dodo::persist::sqlite::DDL::execute(), and dodo::persist::sqlite::Statement::prepare().

Here is the call graph for this function:

◆ vacuum()

void dodo::persist::KVStore::vacuum ( )

Vaccum - clean and defragment, which may increase efficiency after heavy deletion and/or modification.

Definition at line 298 of file kvstore.cpp.

References db_, dodo::persist::sqlite::DDL::execute(), and dodo::persist::sqlite::Statement::prepare().

Here is the call graph for this function:

Field Documentation

◆ db_

sqlite::Database* dodo::persist::KVStore::db_

protected

The database handle.

Definition at line 306 of file kvstore.hpp.

Referenced by checkpoint(), commitTransaction(), createSchema(), KVStore(), optimize(), prepareSQL(), rollbackTransaction(), startTransaction(), vacuum(), and ~KVStore().

◆ path_

std::filesystem::path dodo::persist::KVStore::path_

protected

The filesystem path to the kvstore.

Definition at line 303 of file kvstore.hpp.

Referenced by KVStore().

◆ stmt_delete_

sqlite::DML* dodo::persist::KVStore::stmt_delete_

protected

Delete key pair statement handle.

Definition at line 318 of file kvstore.hpp.

Referenced by deleteKey(), KVStore(), prepareSQL(), and ~KVStore().

◆ stmt_exists_

sqlite::Query* dodo::persist::KVStore::stmt_exists_

protected

check key existence statement handle.

Definition at line 309 of file kvstore.hpp.

Referenced by exists(), KVStore(), prepareSQL(), and ~KVStore().

◆ stmt_getvalue_

sqlite::Query* dodo::persist::KVStore::stmt_getvalue_

protected

Get-value-for-key statement handle.

Definition at line 312 of file kvstore.hpp.

Referenced by getValue(), KVStore(), prepareSQL(), and ~KVStore().

◆ stmt_insert_

sqlite::DML* dodo::persist::KVStore::stmt_insert_

protected

Insert key pair statement handle.

Definition at line 315 of file kvstore.hpp.

Referenced by insertKey(), KVStore(), prepareSQL(), and ~KVStore().

◆ stmt_key_filter_

sqlite::Query* dodo::persist::KVStore::stmt_key_filter_

protected

Key filter statement handle.

Definition at line 324 of file kvstore.hpp.

Referenced by filterKeys(), KVStore(), prepareSQL(), and ~KVStore().

◆ stmt_key_value_filter_

sqlite::Query* dodo::persist::KVStore::stmt_key_value_filter_

protected

Key + value filter statement handle.

Definition at line 327 of file kvstore.hpp.

Referenced by KVStore(), prepareSQL(), and ~KVStore().

◆ stmt_metadata_

sqlite::Query* dodo::persist::KVStore::stmt_metadata_

protected

Get metadata statement handle.

Definition at line 330 of file kvstore.hpp.

Referenced by getMetaData(), KVStore(), prepareSQL(), and ~KVStore().

◆ stmt_update_

sqlite::DML* dodo::persist::KVStore::stmt_update_

protected

Update key pair statement handle.

Definition at line 321 of file kvstore.hpp.

Referenced by KVStore(), prepareSQL(), setKey(), and ~KVStore().

The documentation for this class was generated from the following files:

src/include/persist/kvstore/kvstore.hpp
src/lib/persist/kvstore/kvstore.cpp

Data Structures

Public Member Functions

Protected Member Functions

Protected Attributes

Detailed Description

Constructor & Destructor Documentation

◆ KVStore()

◆ ~KVStore()

Member Function Documentation

◆ checkpoint()

◆ commitTransaction()

◆ createSchema()

◆ deleteKey()

◆ ensureWithDefault() [1/3]

◆ ensureWithDefault() [2/3]

◆ ensureWithDefault() [3/3]

◆ exists()

◆ filterKeys()

◆ getMetaData()

◆ getValue() [1/4]

◆ getValue() [2/4]

◆ getValue() [3/4]

◆ getValue() [4/4]

◆ insertKey() [1/4]

◆ insertKey() [2/4]

◆ insertKey() [3/4]

◆ insertKey() [4/4]

◆ optimize()

◆ prepareSQL()

◆ rollbackTransaction()

◆ setKey() [1/4]

◆ setKey() [2/4]

◆ setKey() [3/4]

◆ setKey() [4/4]

◆ startTransaction()

◆ vacuum()

Field Documentation

◆ db_

◆ path_

◆ stmt_delete_

◆ stmt_exists_

◆ stmt_getvalue_

◆ stmt_insert_

◆ stmt_key_filter_

◆ stmt_key_value_filter_

◆ stmt_metadata_

◆ stmt_update_
